EN
3.1.2.2
Serial number KHS HS2 Hygiene flushing box
Serial number of KHS Flush Box PRO on type plate
Main view
When all the devices have been added, they are
displayed in the main view, as shown below.
Device settings
3.1.2.3
In the „Device settings" submenu, the individual
Control System are logically assigned to the
Control type
Description
B valve
Terminal flushing valve, with several A valves hydraulically preconnected.
A valve
Depending on the type of valve, A valves switch the water exchange of a line
or set up the hydraulic balacing in a cold water circulation
C valve
Terminal flushing valve for one line.
Safety device
Valve which protects a distribution line.
Only measurement
Slave for the acquisition and long-term monitoring of sensor values.
110/265 – K410068602008-00 / 01.2023 – © www.kemper-group.com
CAN bus setup
The individual devices can then be configured in
Device settings.
Note!
Check to see if the CAN bus icon can always be seen on the
main screen for each connected device and if the LEDs light
up green on all system controls and hygiene flushing boxes.
Only then has a proper connection been established.
integrated actuators and sensors.
The valve control type is also determined.
