Danfoss VLT Midi Drive FC 280 Installationshandbuch Seite 134

VLT® Midi Drive FC 280
2.9
[mm (in)] a
b
c
d
e
f
130 | Danfoss A/S © 2022.06
b
c
b
K1 K2
198 (7.8) 260 (10.2)
60 (2.4) 70 (2.8)
5 (0.2) 6.4 (0.25)
9 (0.35) 11 (0.43)
4.5 (0.18) 5.5 (0.22)
7.3 (0,29) 8.1 (0,32)
e
f
a
d
e
a
K3 K4
260 (10.2) 297.5 (11.7)
90 (3.5) 105 (4.1)
6.5 (0.26) 8 (0.32)
11 (0.43) 12.4 (0.49)
5.5 (0.22) 6.8 (0.27)
9.2 (0.36) 11 (0.43)
K5
390 (15.4)
120 (4.7)
7.8 (0.31)
12.6 (0.5)
7 (0.28)
11.2 (0.44)
AN41533976851001-000101 / 130R1257
