3.4. Bodywork parts reference colours (F4 RR)

Bodywork parts are painted with the following reference colours, according to the corresponding
motorcycle colour combination:
1. - Front fairing:
Colour code A:
Crayon Red (Code Palinal 926R750) +
MV Crayon ICE White
(Code Palinal 929.F364)
Colour code B:
Matt Pearly White (Code Dr. A. Schoch
AG 3610-002931 + Palinal Matt 4 TIXO) +
Matt Intense Black (Code Palinal
929XR486 + Palinal Matt 4 TIXO)
2. - Left-hand side fairing;
3. - Right-hand side fairing;
Colour code A:
Crayon Red (Code Palinal 926R750) +
MV Crayon ICE White
(Code Palinal 929.F364)
Colour code B:
Matt Pearly White (Code Dr. A. Schoch
AG 3610-002931 + Palinal Matt 4 TIXO)
All manuals and user guides at all-guides.com
TECHNICAL INFORMATION
4. - Left-hand rearview mirror;
5. - Right-hand rearview mirror;
6. - Airbox;
7. - Fuel tank;
8. - Rear left side panel;
9. - Rear right side panel;
10.- Undercowl;
11.- Front mudguard;
12. - Fuel tank left-hand side fairing;
13. - Fuel tank right-hand side fairing;
14. - Front fairing spoiler:
- 79 -
Colour code A:
Crayon Red (Code Palinal 926R750)
Colour code B:
Matt Pearly White (Code Dr. A. Schoch
AG 3610-002931 + Palinal Matt 4 TIXO)
Colour code A:
MV Crayon ICE White
(Code Palinal 929.F364)
Colour code B:
Matt Intense Black (Code Palinal
929XR486 + Palinal Matt 4 TIXO)
