3.3. Bodywork parts reference colours (F4 R)

Bodywork parts are painted with the following reference colours, according to the corresponding
motorcycle colour combination:
1. - Front fairing;
2. - Right-hand rearview mirror;
3. - Left-hand rearview mirror;
4. - Air box;
5. - Fuel tank:
Colour code A:
Crayon Red (Code Palinal 926R750)
Colour code B:
MV Crayon ICE White
(Code Palinal 929.F364)
6. - Rear right side panel;
7. - Rear left side panel:
Colour code A:
Metal Medium Titanium Grey
(Code Palinal L820)
Colour code B:
MV Crayon ICE White
(Code Palinal 929.F364)
All manuals and user guides at all-guides.com
TECHNICAL INFORMATION
8. - Right-hand side fairing;
9. - Left-hand side fairing;
10. - Undercowl;
11. - Fuel tank right-hand side fairing;
12. - Fuel tank left-hand side fairing:
- 77 -
Colour code A:
Metal Medium Titanium Grey
(Code Palinal L820)
Colour code B:
"Senna" Metal Anthracite
(Code PPG GM WA9561)
