A - Engine: four-stroke, inline four-cylinder.
Double-overhead camshaft valve train with
radial valves. Wet sump lubrication.
B - Ignition - Power supply: integrated ignition-
injection system. Inductive-discharge electro-
nic ignition. "Multipoint" electronic injection.
C - Gearbox: removable, six-speed, with con-
stant-mesh gears.
D - Final drive: consisting of drive sprocket, rear
sprocket and chain.
E - Cooling system: with separate liquid and oil
radiators.
F - Frame: tubular steel trellis with aluminium
side plates.
All manuals and user guides at all-guides.com
TECHNICAL INFORMATION
G - Front suspension: upside-down hydraulic
H - Rear suspension: progressive, with single-
I - Battery: sealed and maintenance-free.
L - Front brake: dual semi-floating disc with
M - Rear brake: single disc with four-piston cali-
N - Instrument panel: with warning lights and
O - Exhaust system: equipped with catalytic
- 61 -
fork with external adjusting system.
sided swingarm and single shock absorber
with external adjusting system.
four-piston calipers.
per.
digital instruments.
converter for exhaust emission reduction.
