4. OPERATION

The installation must be performed by a qualified professional.
Please, check each time before using, the electrical connections and the cables are not damaged. Also, it
is NOT recommended to perform, for example, a cable extension. It is not certain whether this modification
is technically correct, so this warranty is void. It must be ensured that the pump is sufficiently cooled during
prolonged operation.
Diesel pumps are electrical products, which have to be protected against outer influences, f.e. caused by weather.
Only use the pump in well-ventilated rooms and areas with enough fresh air. The floor, on which the pump may be
used, should be flat. Please keep enough space from walls.
The specified suction lift is the maximum suction at optimal conditions. Do not reduce the cross area of suction and
discharge lines.
CAUTION: Do not connect more than 4m of 1" hose on the pressure side. For smaller hose diameters,
use shorter hose. Operation with dispensing guns is not recommended and is therefore at your own risk.
These measures must be strictly adhered to in order to avoid damage to the pump.
Installation of the barrel pump
1. Connect all parts correctly and ensure outlet connections are in proper placement.
2. Apply power cord to the motor by plugging the power cord into a power source. Turn on the pump by use the on/off swich.
The flow of the 230 volt pump can be adjusted with the flow regulating screw.
3. Refuel as usual.
4. When fueling is complete, return the nozzle to its storage position and turn off the pump.
DIESEL/AdBlue 230V BARREL PUMP
®
DIESEL 12V / 24V BARREL PUMP
English 02
--
+
