Technical Data - KNF Laboport N96 Originalbetriebsanleitung

Laboratory pump Laboport® N96
Translation of Original Operating Instruction, KNF 323241-323242 06/22

4 Technical data

Technical data
Pump materials
Assembly
Pump head
Diaphragm
Valves
Tab.5: Pump materials
Pneumatic data
Parameter
Max. permissible operating
pressure [bar rel*]
Ultimate vacuum [mbar abs.] <130
Flow rate at atm. pressure [l/
min]**
Tab.6: Pneumatic data
*Bar rel related to 1013 hPa
**Liters in standard state (1013 hPa, 20°C)
Pneumatic connections
Pump type
Laboport N96
Tab.7: Pneumatic connections
Electrical data
Pump
Parameter
Voltage [V]
Power P [W]
Max. permissible mains volt-
age fluctuations
Current consumption [A]
Tab.8: Electrical data of pump
Material
PPS
PTFE-coated
FPM
Value
2,5
1,5 -7,0 ± 10%
Value
NPT 1/8
Value
24 DC
19
± 10%
0,9
Technical data
DE
EN
FR
ES
IT
13
