1.6 Technical Specifications

Name Value
Temperature (operating) -20 – 60 °C (with battery); -20 – 85 °C (without battery)
Temperature (charging) 0 – 40 °C
Storage Temperature Range -20 – 60 °C
Humidity 10 – 90 %, non-condensing
Air Pressure 50 – 110 kPa (with battery); 30 – 110 kPa (without battery)
IP Rating IP 54 (IEC 60529)
Voltage 5 V DC
Current Consumption up to 150 mA
Transmitting Power 2.5 mW
BLE Frequency Band 2.402 – 2.480 GHz
Risk of Short Circuits!
Notice
Liquid which enters the device can damage the device due to short
circuits. This causes the risk of fire.
• Do not allow any fluids to enter the CISS.
• Use the device only as specified.
Lithium-Ion Battery!
Notice
The device contains a lithium-ion battery. Incorrect handling of the
battery causes the risk of fire.
• Protect the CISS from mechanical shocks and impacts.
• Read and follow the valid transportation regulations, if necessary.
Voiding the Warranty!
Notice
Opening of the housing without authorisation causes risk to the
user and will void the warranty.
• Do not open the housing.
• Use only original or approved accessories.
Functional Limitations!
Notice
The device can be impaired or damaged if the connections are not
connected correctly.
• Use only the delivered connection cable.
• Use only 5 V DC USB power supply.
0274VM0944 v1.3 | 01.2017
english
Robert Bosch GmbH
1 1 | CISS-R2 english
2 Connection and Putting into Operation
2.1. Attachment
The CISS is built into an automotive housing.
Use the screws and washers included in delivery to mount the CISS
to the desired position.
If a magnetic mounting is required, apply the included screws to the
bottom of the CISS. With these screws applied, the CISS can be moun-
ted to any magnetic surface.

2.2. Putting into Operation

Connect the USB cable included in delivery to the CISS and to the
USB power supply (such as a PC or a power adapter). The CISS is
now ready to be put into operation:
The data logger application is pre-installed and can be configured in
the WebApp of the gateway (see 2.3.2 or the user guide).
Corresponding firmware is required for each CISS application. This
firmware is pre-installed when delivered. A change of the application
requires a firmware update (see 2.3.4 or the user guide).

2.3. Data Transfer

Data can be transferred in three ways:
• Mobile app (data display only)
• Gateway (Raspberry Pi)
• PC
2.3.1 Mobile App (Beta Version)
Communication channel: Bluetooth Low Energy
Options: Configuration
2.3.2 Gateway
Communication channel: Bluetooth Low Energy
Options: Configuration, measurement data transmission to the
gateway and transfer to the Sensor Cloud
