8. Technical Data

CLX Series
CLX Home GM
CLX Standard GM
CLX Standard
Processor
Display
Interfaces
Terminal strips 12-way
Enclosure
Weight
Humidity
Ambient humidity
Operating temperature
Dimensions (without screws
and mounting plate)
Power
Standby Power Consumption
*) Not used.
**) Not used in CLX Standard.
32-bit microcontroller, 96 MHz
Display 4x20 LCD ASCII backlit
LAN (Ethernet 10/100 Mbit)
CLX Home GM and CLX Standard GM: RS-485
Easylan for connecting a Danfoss Sensor Interface box.
4 **) + 2 *) x digital input (self-powered), without galvanic isolation for ex-
ternal floating contact
2 x 4-20 mA input: analogue input, without galvanic isolation
2-part, fanless metal enclosure for rail mounting (IP20), DIN rail
330 g net (without accessories and external AC mains adapter)
< 80% non-condensing
Indoor/switch cabinet installation
0 to 50 °C
160 mm x 100 mm x 31 mm (W x H x D)
12–30 VDC
Approx. 1 Watt
