7. Application and Data

7.1. Main Page

When starting the Danfoss SolarApp after the initial configuration, either through a Smart-
phone, a tablet or using the PC and a browser plugin, the following main page is shown:
Illustration 7.1: Main Page
Allow a few minutes from power-on of the CLX product for correct values to be shown on the
main page (allow time for initial data collection).
The main page displays all the important plant production data including a user-definable plant
name and the current 'date and time' settings. For configuration, see the
From the main page navigate to pages with more detailed information by clicking on the indi-
vidual circles and links:
• Click on 'View production' (large circle to the left) to see graphs with production data,
see the
• Click on 'View status' (upper right circle) to see detailed status of the connected inver-
ters and current power output, see the
• The lower right circle shows how much CO
electricity production. It does not link to a page, but by using 'Toggle' the user can
switch between total CO
• Click on 'Settings' (lower right corner) to navigate to detailed settings, see the
section.
Production Graphs section.
savings and total revenue.
2
L00410601-06_5b
7. Application and Data
Settings sections.
Plant Status section.
the plant has saved, compared to standard
2
7
Settings
21
