• Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
• Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
Safety instructions for hammers
• Wear hearing protection. Excessive noise can
result in a loss of hearing.
• Use the additional grips if these are supplied with
the electric tool. Loss of control can lead to injuries.
• When performing work during which the tool
attachment can meet with concealed power lines
or its own mains cable, hold the device by the
insulated gripping surfaces. Contact with a live
power line can also electrify metal device parts and
lead to an electric shock.
• Use the appropriate detection devices in order to
detect hidden supply lines or consult the local utility
company. Contact with electrical lines can result
in fire and electric shock. Damage to a gas line
can lead to an explosion. Penetrating a water pipe
causes property damage or may cause an electric
shock.
• Hold the electrical tool firmly with both hands and
ensure firm footing. It is safer to guide the electrical
tool with two hands.
• Secure the workpiece. A workpiece held with a
clamping device or vice is held more securely than
with your hand.
• Wait until the electrical tool has come to a standstill
before setting it down. The tool attachment can get
caught and this can lead to loss of control over the
electric tool.
Keep the noise level and vibration to a minimum!
• Only use devices which are free of defects.
• Maintain and clean the device at regular intervals.
• Adapt your working methods to the device.
• Do not overload the device.
• Have the device checked if necessary.
• Switch the device off if it is not in use.
• Wear gloves.
m ATTENTION!
This power tool generates an electromagnetic field
during operation. This field can impair active or
passive medical implants under certain conditions. In
order to prevent the risk of serious or deadly injuries,
we recommend that persons with medical implants
consult with their physician and the manufacturer of
the medical implant prior to operating the machine.
Residual risks
The machine has been built according to the state-
of-the-art and the recognised technical safety
requirements. However, individual residual risks can
arise during operation.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Before performing setting or maintenance work,
release the start button and pull out the power plug.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still
remain.
• Residual risks can be minimised if the "Safety
information" and the "Proper use" together with the
operating manual as a whole are observed.
• Avoid accidental starting of the machine: the
operating button may not be pressed when
inserting the plug in an outlet. Use the tool that
is recommended in this operating manual. This is
how to ensure that your machine provides optimum
performance.
• Keep your hands away from the work area, when
the machine is in operation.

6. Technical data

Stroke rate
Dimensions L x W
x H
Impact force
Engine
Rated input P1
Protection class
P r o t e c t i o n
category
Retainer
Technical changes reserved!
Noise & vibration
m Warning: Noise can have serious effects on your
health. If the machine noise exceeds 85 dB (A),
please wear suitable hearing protection.
Noise data
Sound power level L
Sound pressure level L
Uncertainty K
Vibration parameters
Vibration a
Vibration a
Uncertainty K
www.scheppach.com
470 x 240 x 95 mm
220 - 240 V~ / 50 Hz
SDS - MAX System
102,5 dB(A)
WA
88,5 dB(A)
pA
2,46 dB(A)
wa/pA
(handle) 16.475 m/s²
h
(additional handle) 17.242 m/s²
h
1.5 m/s²
h
4600 min
-1
27 J
1300 W
II
IP20
