Comando RS232

Assegnazione dei pin RS232

N. Seriale
1 N.C
2 RXD
3 TXD
4 N.C
5 Terra

Porta seriale RS232 con un cavo crossover

Funzione Tipo
Write
Power Write
Read
Write
Write
Write
Source
Write
Selection
Write
Write
Read
Write
Write
Read
Audio Control Write
Write
Write
Read
N. Seriale
6 N.C
7 Corto con pin 8
8 Corto con pin 7
9 N.C
Funzionamento
Power On
Power Off
Power Status
COMPUTER/YPbPr
COMPUTER 2/YPbPr2
DVI-D
HDMI(MHL)
HDMI 2(MHL2)
HDBaseT
Current source
Mute On
Mute Off
Mute Status
Volume +
Volume -
Volume level for customer
Volume Status
1 2 3 4 5
6 7 8 9
ASCII
<CR>*pow=on#<CR>
<CR>*pow=off#<CR>
<CR>*pow=?#<CR>
<CR>*sour=RGB#<CR>
<CR>*sour=RGB2#<CR>
<CR>*sour=dvid#<CR>
<CR>*sour=hdmi#<CR>
<CR>*sour=hdmi2#<CR>
<CR>*sour=hdbaset#<CR>
<CR>*sour=?#<CR>
<CR>*mute=on#<CR>
<CR>*mute=off#<CR>
<CR>*mute=?#<CR>
<CR>*vol=+#<CR>
<CR>*vol=-#<CR>
<CR>*vol=value#<CR>
<CR>*vol=?#<CR>
165
