Projector dimension ................15 RS232 command control ..............16 RS232 pin assignment ....................16 RS232 serial port with a crossover cable ..............16 PJLink ..........................23 Please visit below website for latest version of User Manual / Installation Guide. http://business-display.benq.com/ V1.00...
Notice Notice on laser Caution – use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Do not point laser or allow laser light to be directed or reflected toward other people or reflective objects.
Cooling notice Allow at least 50 cm (19.7 inch) for clearance around the exhaust vent. Make sure no objects block air inlet within 50 cm (19.7 inch). Keep the outlet at least 1 m away from the inlets of other projectors. Air outlet Air inlet •...
Seite 5
• Allow at least 50 cm of clearance around the exhaust vent. Minimum 50 cm Minimum 50 cm (19.69 inch) (19.69 inch) Minimum 50 cm (19.69 inch) Minimum 100 cm (39.37 inch) Minimum 50 cm (19.69 inch) • Ensure that the air intake vents do not recycle hot air from the exhaust vent. •...
Make sure the port is valid before inserting a wired remote controller. The remote controller may be damaged in case of an invalid port, e.g. a wired remote controller is connected to trigger output. For more information about upgrading firmware via Lan, please contact BenQ service.
Remote control ON / OFF Toggles the projector between standby mode and on. KEYSTONE+/KEYSTONE- Manually corrects distorted images resulting from an angled projection. VOLUME +/VOLUME - Increases/decreases the projector volume. QUICK INSTALL Displays the Quick Install OSD menu. MUTE Toggles projector audio between on and off. Arrow keys (▲...
Seite 9
OVERSCAN Press to select overscan mode. FREEZE Freezes the projected image. LAMP MODE Press to display OSD menu to select desired light mode. 3D MODE Press to display 3D setup menu. INFO. Press to display INFORMATION menu. LIGHT Press to open backlight of remote controller. CLEAR Clear remote ID SET assigned to all projectors.
Installation Lens Cap / Lens Lock 1. Remove lens cap before booting. 2. Install lens lock 3. Secure with screws, do not fully tighten 4. Adjust the focus 5. Tighten the screws...
Projection table • LU960ST The screen aspect ratio is 16:10 and the projected picture is 16:10. Note: To optimize the projection quality, we suggest to project images in an area without grayscale. Image size Distance Diagonal Width Height Min distance - Wide...
Seite 12
Note: • For more visualized instructions, please go to BenQ calculator website http://projectorcalculator.benq.com/. • Ceiling installation must be done by a qualified professional. Contact your dealer for more information. It is not recommended you install the projector yourself. • Only use the projector on a solid, level surface. Serious injury and damage can occur if the projector is dropped. • Do not use the projector in an environment where extreme temperature occurs. The projector must be used at temperatures between 41 degrees Fahrenheit (5 degrees Celsius) and 104 degrees Fahrenheit (40 degrees Celsius). • Screen damage will occur if the projector is exposed to moisture, dust or smoke. • Do not cover the vents on the projector. Proper ventilation is required to dissipate heat. Damage to the projector will occur if the vents are covered. y Lens shift range diagram • LU960ST / LU960 Normal projection position Desk-Front Projection Vertical shift Max 0.62V Height of projected image Vertical shift Max 0.62V 0.24H 0.24H Width of projected image Ceiling Mount-Front Projection...
LED indicator y LED Usage LED Name Detailed Description Display the power on/off sequence status Orange : Power Off (Green + Red) Power LED Green : Power On Blink : Warming up/Shutting Down & Cooling / Error Code Display the Thermal status (Fan Fail, Over Temperature, etc.) Temperature Status LED Red : Thermal Over Temperature...
y Burn-In Messages Power Temp Light Status & Description Burn-in ON Green Burn-in OFF Green Green Green y Lamp Error Messages Power Temp Light Status & Description Lamp1 error in normal operation Lamp is not lit up Flashing y Thermal Error Messages Power Temp Light...
Seite 15
Power Temp Light Status & Description Thermal Sensor 3 open error Green Flashing Thermal Sensor 3 short error Green Green Green Thermal IC #3 I2C Connection error Green Flashing Temperature 4 error (over limited temperature) Green Flashing Thermal Sensor 4 open error Green Flashing Flashing...
RS232 command control RS232 pin assignment Serial Serial Short with pin8 Short with pin7 Ground RS232 serial port with a crossover cable Function Type Operation ASCII Power Write Power On <CR>*pow=on#<CR> Write Power Off <CR>*pow=off#<CR> Read Power Status <CR>*pow=?#<CR> Source Write COMPUTER/YPbPr <CR>*sour=RGB#<CR>...
Seite 18
Function Type Operation ASCII Audio Source Write Audio pass Through off <CR>*audiosour=off#<CR> Select Write Audio-Computer1 <CR>*audiosour=RGB#<CR> Write Audio-HDMI <CR>*audiosour=hdmi#<CR> Write Audio-HDMI2 <CR>*audiosour=hdmi2#<CR> Write DisplayPort <CR>*audiosour=dp#<CR> Write HDBaseT <CR>*audiosour=hdbaset#<CR> Read Audio pass Status <CR>*audiosour=?#<CR> Picture Mode Write Presentation <CR>*appmod=preset#<CR> Write sRGB <CR>*appmod=srgb#<CR>...
Seite 19
Function Type Operation ASCII Picture Setting Write Aspect Auto <CR>*asp=AUTO#<CR> Write Aspect Real <CR>*asp=REAL#<CR> Write Aspect 2.4:1 <CR>*asp=2.4#<CR> Read Aspect Status <CR>*asp=?#<CR> Write Vertical Keystone + <CR>*vkeystone=+#<CR> Write Vertical Keystone - <CR>*vkeystone=-#<CR> Write Set Vertical Keystone value <CR>* vkeystone=value#<CR> Read Vertical Keystone value <CR>*vkeystone=?#<CR>...
Seite 20
Function Type Operation ASCII Picture Setting Write Brilliant color + <CR>*BC=+#<CR> Write Brilliant color - <CR>*BC=-#<CR> Write Brilliant color set value <CR>*BC=value#<CR> Read Brilliant color status <CR>*BC=?#<CR> Write Auto(HDR) <CR>*hdr=auto#<CR> Write <CR>*hdr=sdr#<CR> Write HDR10 <CR>*hdr=hdr#<CR> Write <CR>*hdr=hlg#<CR> Read HDR status <CR>*hdr=?#<CR>...
Seite 21
Function Type Operation ASCII Lamp Control Write Eco mode <CR>*lampm=eco#<CR> Write Dimming mode <CR>*lampm=dimming#<CR> Write Custom mode <CR>*lampm=custom#<CR> Write Light level for custom mode <CR>*lampcustom=value#<CR> Read Light level status for custom mode <CR>*lampcustom=?#<CR> Read Lamp Mode Status <CR>*lampm=?#<CR> Miscellaneous Read Model Name <CR>*modelname=?#<CR>...
Seite 22
Function Type Operation ASCII Miscellaneous Read Remote Receiver Status <CR>*rr=?#<CR> Write AMX Device Discovery-on <CR>*amxdd=on#<CR> Write AMX Device Discovery-off <CR>*amxdd=off#<CR> Read AMX Device Discovery Status <CR>*amxdd=?#<CR> Read Mac Address <CR>*macaddr=?#<CR> Read Serial Number <CR>*serialnumber=?#<CR> Write High Altitude mode on <CR>*Highaltitude=on#<CR> Write High Altitude mode off <CR>*Highaltitude=off#<CR>...
Seite 23
Function Type Operation ASCII Color Read Primary Color Status <CR>*primcr=?#<CR> Calibration Write Hue + <CR>*hue=+#<CR> Write Hue - <CR>*hue=-#<CR> Write Set Hue value <CR>*hue=value#<CR> Read Get Hue value <CR>*hue=?#<CR> Write Saturation + <CR>*saturation=+#<CR> Write Saturation - <CR>*saturation=-#<CR> Write Set Saturation value <CR>*saturation=value#<CR>...
5th byte Return 0 Indicates other errors, and 6th byte returns 0 - 2 Light source sta- LAMP? xxxxxxxxxxxx 1st number (1-5 digitals): Light source 1 runtime tus query Input selection 11 12 21 31 32 33 INST? LU960ST list query...
Seite 25
WORK SETUP] Manufacturer INF1? BenQ Returns manufacturer name name query Model name que- INF2? LU960ST Returns moder name Other informa- INF0? xxxxx Returns information such as version number tion queries Class information CLASS? Returns class for PJLink query Note: RS-232 baud rate options are 2400, 4800, 9600, 14400, 19200, 38400, 57600 and 115200 (Default : 115200).
連接有線遙控器。 連接 Display Port 來源。 HDMI OUT 連接 HDMI 裝置。 PC IN 15-pin VGA 連接埠, 用於連接 RGB、色差 HD 來源或 PC。 MONITER OUT 連接其他顯示設備, 用於同時播放顯示。 AUDIO OUT 連接揚聲器放大器或耳機。 AUDIO IN 透過音訊連接線連接音訊輸入源。 警告: 請確定在插入有線遙控器之前 ,連接埠有效。若是無效的連接埠,如有效遙控器連接至觸發輸出 ,則遙控器可能 會損壞。如需透過 Lan 升級韌體的詳細資訊 ,請洽詢 BenQ 服務。...
Light source sta- LAMP? xxxxxxxxxxxx 1st number (1-5 digitals): Light source 1 runtime tus query Input selection 11 12 21 31 32 INST? LU960ST list query 33 34 Projector name Returns the name set in [PROJECTOR NAME] of [NET- NAME? xxxxx query...
Seite 49
指令 控制詳細資訊 備註 傳回字串 Manufacturer INF1? BenQ Returns manufacturer name name query 繁 Model name que- INF2? LU960ST Returns moder name 體 中 Other informa- INF0? xxxxx Returns information such as version number 文 tion queries Class information CLASS? Returns class for PJLink query 注意事項:...
产品信息 包装清单 简 体 中 文 规格 LU960ST LU960 1-CHIP DMD 投影系统 1920*1200 像素, 16:10 固有分辨率 光源 激光二极管 0.77 ~ 0.84 1.13 ~ 1.70 投射比例 450W (常模式) /350W (省电模式) 功耗 479.6 x 402 x 182.8 mm 外形尺寸 12 kg 重量...
Seite 55
连接 Display Port 信号源。 连接有线遥控器 HDMI OUT 连接 HDMI 设备。 PC IN 用于连接 RGB、 分量 HD 信号源或 PC 的 15 针 VGA 端口。 MONITER OUT 连接用于同时播放显示的其他显示设备。 AUDIO OUT 连接扬声器放大器或耳机。 AUDIO IN 通过音频线连接音频输入源。 警告 : 在插入有线遥控器之前确保此端口是有效的。 插入到无效的端口中遥控器可能会损坏, 如有线遥控器连接到触发 器输出。 更多关于通过局域网升级固件的信息, 请联系 BenQ 客户服务中心。...
Seite 57
OVERSCAN 按下可选择过扫描模式。 FREEZE 冻结投影图像。 LAMP MODE 按下显示 OSD 菜单以选择所所需光源模式。 3D MODE 按下可显示 3D 设置菜单。 INFO. 按下可显示信息菜单。 简 LIGHT 体 按下可打开遥控器背光。 中 CLEAR 文 清除分配给所有投影机的 ID 设置。 按住 CLEAR 和 ID SET 五秒。 LED 闪烁三下, 之后 ID 设置被清除。 SHUTTER 在此投影机中没有这项功能。 ID SET •...
Seite 67
ASCII 功能 类型 操作 Picture Setting Write Aspect Auto <CR>*asp=AUTO#<CR> Write Aspect Real <CR>*asp=REAL#<CR> Write Aspect 2.4:1 <CR>*asp=2.4#<CR> Read Aspect Status <CR>*asp=?#<CR> Write Vertical Keystone + <CR>*vkeystone=+#<CR> Write Vertical Keystone - <CR>*vkeystone=-#<CR> Write Set Vertical Keystone value <CR>* vkeystone=value#<CR> 简 Read Vertical Keystone value <CR>*vkeystone=?#<CR>...
Seite 68
ASCII 功能 类型 操作 Picture Setting Write Brilliant color + <CR>*BC=+#<CR> Write Brilliant color - <CR>*BC=-#<CR> Write Brilliant color set value <CR>*BC=value#<CR> Read Brilliant color status <CR>*BC=?#<CR> Write Auto(HDR) <CR>*hdr=auto#<CR> Write <CR>*hdr=sdr#<CR> Write HDR10 <CR>*hdr=hdr#<CR> Write <CR>*hdr=hlg#<CR> 简 Read HDR status <CR>*hdr=?#<CR>...
Seite 69
ASCII 功能 类型 操作 Miscellaneous Read Model Name <CR>*modelname=?#<CR> Read System F/W Version <CR>*sysfwversion=?#<CR> Read Scaler F/W Version <CR>*scalerfwversion=?#<CR> Read Lan F/W Version <CR>*lanfwversion=?#<CR> Read MCU F/W Version <CR>*mcufwversion=?#<CR> Write Blank On <CR>*blank=on#<CR> Write Blank Off <CR>*blank=off#<CR> 简 Read Blank Status <CR>*blank=?#<CR>...
Seite 70
ASCII 功能 类型 操作 Color Write Tint + <CR>*tint=+#<CR> Calibration Write Tint - <CR>*tint=-#<CR> Write Set Tint value <CR>*tint=value#<CR> Read Get Tint value <CR>*tint=?#<CR> Write Set gamma value <CR>*gamma=value#<CR> Read Gamma value status <CR>*gamma=?#<CR> Write Set HDR Brightness value <CR>*hdrbri=value#<CR> Read Get HDR Brightness value <CR>*hdrbri=?#<CR>...
Seite 71
ASCII 功能 类型 操作 Service Read Error Code report <CR>*error=report#<CR> Read FAN 1 speed <CR>*fan1=?#<CR> Read FAN 2 speed <CR>*fan2=?#<CR> Read FAN 3 speed <CR>*fan3=?#<CR> Read FAN 4 speed <CR>*fan4=?#<CR> Read FAN 5 speed <CR>*fan5=?#<CR> Read FAN 6 speed <CR>*fan6=?#<CR> 简...
Light source sta- LAMP? xxxxxxxxxxxx 1st number (1-5 digitals): Light source 1 runtime tus query Input selection 11 12 21 31 32 INST? LU960ST list query 33 34 Projector name Returns the name set in [PROJECTOR NAME] of [NET- NAME? xxxxx query...
Seite 73
命令 控制详细信息 备注 返回字符串 Manufacturer INF1? BenQ Returns manufacturer name name query Model name que- INF2? LU960ST Returns moder name Other informa- INF0? xxxxx Returns information such as version number tion queries Class information CLASS? Returns class for PJLink 简...
Seite 74
Dimensions du projecteur ..............87 Commande RS232 ................88 Affectation des broches RS232 ................. 88 Port série RS232 avec un câble croisé ..............88 PJLink .......................... 95 Veuillez consulter le site Web ci-dessous pour obtenir la dernière version du Manuel d’utilisation/Guide d’installation. http://business-display.benq.com/ V1.00...
Notice Informations sur le laser Attention – l’utilisation de commandes ou de réglages ou la mise en œuvre de procédures autres que ceux spécifiés dans le présent document peuvent entraîner une exposition dangereuse aux rayonnements. Ne dirigez pas le laser et ne laissez pas la lumière laser être dirigée ou réfléchie vers d’autres personnes ou des objets réfléchissants.
Informations sur le refroidissement Prévoyez au moins 50 cm (19,7 po) de dégagement autour de la sortie de ventilation. Veillez à ce qu'aucun objet ne bloque l'entrée d'air à moins de 50 cm (19,7 po) . La sortie doit être à au moins 1 m des entrées d'autres projecteurs. Sortie d'air Entrée d'air •...
Seite 77
• Prévoyez au moins 50 cm de dégagement autour de la sortie de ventilation. Minimum 50 cm Minimum 50 cm (19,69 po) (19,69 po) Minimum 50 cm (19,69 po) Minimum 100 cm (39,37 po) Minimum 50 cm (19,69 po) • Veillez à...
Assurez-vous que le port est valide avant de connecter une télécommande filaire. La télécommande peut être endommagée en cas d’utilisation d'un port non valide, ex. une télécommande filaire connectée pour déclencher une sortie. Pour plus d’informations sur la mise à niveau du firmware via Lan, veuillez contacter le service BenQ.
Télécommande ON / OFF Permet de faire basculer le projecteur entre les modes veille et activé. KEYSTONE+/KEYSTONE- Permet de corriger manuellement la déformation des images due à l’angle de projection. VOLUME +/VOLUME - Augmente/diminue le volume du projecteur. QUICK INSTALL Affiche le menu OSD Installation rapide.
Seite 81
OVERSCAN Appuyez pour sélectionner le mode surbalayage. FREEZE Met en pause l’image projetée. LAMP MODE Appuyez pour afficher le menu OSD pour sélectionner le mode lumineux souhaité. 3D MODE Appuyez pour afficher le menu de configuration 3D. INFO. Appuyez sur pour afficher le menu INFORMATIONS. LIGHT Appuyez pour ouvrir le rétroéclairage de la télécommande.
Installation Bouchon d'objectif/Verrouillage d’objectif 1. Retirez le bouchon d'objectif avant de démarrer. 2. Installez le verrouillage d'objectif 3. Fixez avec les vis, ne serrez pas complètement 4. Réglez la mise au point 5. Serrez les vis...
Projection table • LU960ST Le rapport d’aspect est 16:10 est l’image projetée est en 16:10. Remarque : Pour optimiser la qualité de la projection, nous conseillons de projeter les images dans une zone sans échelle de gris. Taille d’image Distance...
Seite 84
• Utilisez uniquement le projecteur sur une surface plane et solide. Des blessures graves et des dommages peuvent être causés par la chute du projecteur. • N’utilisez pas le projecteur dans un environnement soumis à des températures extrêmes. Le projecteur doit être utilisé à des températures comprises entre 41 degrés Fahrenheit (5 degrés Celsius) et 104 degrés Fahrenheit (40 degrés Celsius). • L’écran sera endommagé si le projecteur est exposé à l’humidité, à la poussière ou à la fumée. • Ne couvrez pas les fentes d’aération du projecteur. Une ventilation appropriée est nécessaire pour dissiper la chaleur. Le projecteur sera endommagé si les fentes d’aération sont couvertes. y Diagramme de la plage de décalage de l’objectif • LU960ST / LU960 Position normale de projection Bureau-Projection avant Décalage vertical Maxi 0,62V Hauteur de l’image projetée Décalage vertical Maxi 0,62V 0,24H 0,24H Montage au plafond- Projection avant Largeur de l’image projetée...
Indicateur DEL y D'utilisation de LED Nom LED Description détaillée Affiche le statut de la séquence de mise sous tension/hors tension Orange : Hors tension (Vert + Rouge) LED d’alimentation Vert : Sous tension Clignotant : Préchauffage/Arrêt et Refroidissement / Code d’erreur Affiche le statut thermique (Échec ventilateur, Température excessive, etc.)
Seite 86
y Messages de rémanence d’image Tempér- Alimentation Éclairage Statut et description ature Vert Rémanence d’image activée Vert Vert Vert Rémanence d’image désactivée y Messages d’erreurs des lampes Tempér- Alimentation Éclairage Statut et description ature Rouge Erreur lampe 1 en fonctionnement normal Rouge La lampe n’est pas allumée Clignotante...
Seite 87
Tempér- Alimentation Éclairage Statut et description ature Erreur température 3 (dépassement de la limite de Vert Rouge Rouge température) Rouge Vert Rouge Erreur capteur thermique 3 ouvert Clignotante Vert Rouge Vert Erreur capteur thermique 3 en court-circuit Vert Vert Rouge Erreur connexion I2C CI thermique 3 Clignotante Rouge...
Commande RS232 Affectation des broches RS232 N° Série N° Série Court avec broche 8 Court avec broche 7 Terre Port série RS232 avec un câble croisé Fonction Type Fonctionnement ASCII Power Write Power On <CR>*pow=on#<CR> Write Power Off <CR>*pow=off#<CR> Read Power Status <CR>*pow=?#<CR>...
Seite 90
Fonction Type Fonctionnement ASCII Audio Source Write Audio pass Through off <CR>*audiosour=off#<CR> Select Write Audio-Computer1 <CR>*audiosour=RGB#<CR> Write Audio-HDMI <CR>*audiosour=hdmi#<CR> Write Audio-HDMI2 <CR>*audiosour=hdmi2#<CR> Write DisplayPort <CR>*audiosour=dp#<CR> Write HDBaseT <CR>*audiosour=hdbaset#<CR> Read Audio pass Status <CR>*audiosour=?#<CR> Picture Mode Write Presentation <CR>*appmod=preset#<CR> Write sRGB <CR>*appmod=srgb#<CR>...
Seite 91
Fonction Type Fonctionnement ASCII Picture Setting Write Aspect Auto <CR>*asp=AUTO#<CR> Write Aspect Real <CR>*asp=REAL#<CR> Write Aspect 2.4:1 <CR>*asp=2.4#<CR> Read Aspect Status <CR>*asp=?#<CR> Write Vertical Keystone + <CR>*vkeystone=+#<CR> Write Vertical Keystone - <CR>*vkeystone=-#<CR> Write Set Vertical Keystone value <CR>* vkeystone=value#<CR> Read Vertical Keystone value <CR>*vkeystone=?#<CR>...
Seite 92
Fonction Type Fonctionnement ASCII Picture Setting Write Brilliant color + <CR>*BC=+#<CR> Write Brilliant color - <CR>*BC=-#<CR> Write Brilliant color set value <CR>*BC=value#<CR> Read Brilliant color status <CR>*BC=?#<CR> Write Auto(HDR) <CR>*hdr=auto#<CR> Write <CR>*hdr=sdr#<CR> Write HDR10 <CR>*hdr=hdr#<CR> Write <CR>*hdr=hlg#<CR> Read HDR status <CR>*hdr=?#<CR>...
Seite 93
Fonction Type Fonctionnement ASCII Lamp Control Write Eco mode <CR>*lampm=eco#<CR> Write Dimming mode <CR>*lampm=dimming#<CR> Write Custom mode <CR>*lampm=custom#<CR> Write Light level for custom mode <CR>*lampcustom=value#<CR> Read Light level status for custom mode <CR>*lampcustom=?#<CR> Read Lamp Mode Status <CR>*lampm=?#<CR> Miscellaneous Read Model Name <CR>*modelname=?#<CR>...
Seite 94
Fonction Type Fonctionnement ASCII Miscellaneous Read Remote Receiver Status <CR>*rr=?#<CR> Write AMX Device Discovery-on <CR>*amxdd=on#<CR> Write AMX Device Discovery-off <CR>*amxdd=off#<CR> Read AMX Device Discovery Status <CR>*amxdd=?#<CR> Read Mac Address <CR>*macaddr=?#<CR> Read Serial Number <CR>*serialnumber=?#<CR> Write High Altitude mode on <CR>*Highaltitude=on#<CR> Write High Altitude mode off <CR>*Highaltitude=off#<CR>...
Seite 95
Fonction Type Fonctionnement ASCII Color Read Primary Color Status <CR>*primcr=?#<CR> Calibration Write Hue + <CR>*hue=+#<CR> Write Hue - <CR>*hue=-#<CR> Write Set Hue value <CR>*hue=value#<CR> Read Get Hue value <CR>*hue=?#<CR> Write Saturation + <CR>*saturation=+#<CR> Write Saturation - <CR>*saturation=-#<CR> Write Set Saturation value <CR>*saturation=value#<CR>...
PJLink y Protocole PJLink La fonction réseau de ce projecteur prend en charge PJLink classe 1 et le protocole PJLink peut être utilisé pour effectuer des opérations de réglage du projecteur et de consultation du statut du projecteur depuis un ordinateur. y Commandes de contrôle Le tableau suivant indique les commandes du protocole PJLink pouvant être utilisées pour contrôler le projecteur.
Seite 97
Détails du Paramètre / Commande Remarque contrôle Chaîne de retour Input selection INST? 11 12 21 31 32 33 34 LU960ST list query Projector name Returns the name set in [PROJECTOR NAME] of NAME? xxxxx query [NETWORK SETUP] Manufacturer INF1?
Seite 98
Projection table ......................106 LED-Anzeige ..................108 Projektionsmaße ................. 111 RS-232-Befehl ..................112 RS-232-Pinbelegung ....................112 Serieller RS-232-Anschluss mit gekreuztem Kabel ..........112 PJLink .......................... 119 Auf der nachstehenden Webseite finden Sie die aktuellste Version der Bedienungsanleitung / Installationsanleitung. http://business-display.benq.com/ V1.00...
Notice Hinweis zum Laser Achtung – Bei Verwendung von Reglern oder bei Einstellungen oder der Ausführung von Vorgängen, die hier nicht beschrieben sind, kann es zu einer gefährlichen Strahlenbelastung kommen. Richten Sie den Laser weder direkt noch reflektierend auf Personen oder reflektierende Gegenstände.
Hinweis zu Kühlung Halten Sie einen Freiraum von mindestens 50 cm rund um die Abluftöffnungen ein. Achten sie darauf, dass die Zuluftöffnungen in einem Umkreis von 50 cm nicht blockiert werden. Die Abluftöffnungen müssen mindestens 1 m von Zuluftöffnungen anderer Projektoren entfernt sein.
Seite 101
• Halten Sie einen Freiraum von mindestens 50 cm rund um die Abluftöffnungen ein. Mindestens 50 cm Mindestens 50 cm (19,69 Zoll) (19,69 Zoll) Mindestens 50 cm (19,69 Zoll) Mindestens 100 cm (39,37 Zoll) Mindestens 50 cm (19,69 Zoll) • Stellen Sie sicher, dass die Zuluftöffnungen nicht die von den Abluftöffnungen ausgegebene heiße Luft ansaugen.
Stellen Sie sicher, dass der Port gültig ist, bevor Sie eine kabelgebundene Fernbedienung einstecken. Die Fernbedienung könnte im Falle eines ungültigen Ports beschädigt werden, bspw. bei Anschluss einer kabelgebundenen Fernbedienung an den Auslöserausgang. Weitere Informationen zur Aktualisierung der Firmware per WLAN erhalten Sie vom BenQ-Kundendienst.
Remote control ON / OFF Schaltet zwischen Bereitschaftsmodus und Betriebsmodus des Projektors KEYSTONE+/KEYSTONE- Korrigiert manuell Bildverzerrungen, die von einer abgewinkelten Projektion stammen. VOLUME +/VOLUME - Erhöht/verringert die Projektorlautstärke. QUICK INSTALL Ruft das Schnellinstallation-Menü auf. MUTE Schaltet die Tonausgabe des Projektors ein und aus. Pfeiltasten (▲...
Seite 105
OVERSCAN Zur Auswahl des Overscan-Modus drücken. FREEZE Zeigt das projizierte Bild als Standbild an. LAMP MODE Zum Einblenden des OSD-Menüs drücken; wählen Sie dann den gewünschten Lichtmodus. 3D MODE Zur Anzeige des 3D-Einrichtungsmenüs drücken. INFO. Zur Anzeige des INFORMATIONEN-Menüs drücken. LIGHT Zum Aktivieren der Fernbedienungshintergrundbeleuchtung drücken.
Installation Objektivkappe / Objektivsperre 1. Nehmen Sie die Objektivkappe ab, bevor Sie das Gerät hochfahren. 2. Objektivsperre installieren 3. Mit Schrauben befestigen, aber nicht fest anziehen 4. Fokus einstellen 5. Schrauben fest anziehen...
Projection table • LU960ST Das Seitenverhältnis beträgt 16:10 und das projizierte Bild ist 16:10. Hinweis: Zur Optimierung der Projektionsqualität sollten Sie Bilder in einem Bereich ohne Grauskala projizieren. Bildgröße Entfernung Diagonale Breite Höhe Min. Abstand - Mittelwert Max, Abstand - Tele...
Seite 108
Leinwand Hinweis: • Weitere visualisierte Anleitungen finden Sie auf der Webseite des BenQ-Rechners: http://projectorcalculator. benq.com/. • Deckenmontage muss von einem qualifizierten Experten durchgeführt werden. Wenden Sie sich für weitere Informationen an Ihren Händler. Sie sollten den Projektor nicht eigenständig installieren. • Verwenden Sie den Projektor nur auf einem festen, ebenen Untergrund. Falls der Projektor herunterfällt, drohen ernsthafte Verletzungen und Schäden. • Verwenden Sie den Projektor nicht in einer Umgebung mit extremen Temperaturen. Der Projektor muss bei Temperaturen zwischen 5 und 40 Grad Celsius verwendet werden. • Bildschirmschäden treten auf, falls der Projektor Feuchtigkeit, Rauch oder Staub ausgesetzt wird. • Decken Sie die Belüftungsöffnungen am Projektor nicht ab. Zur Wärmeableitung wird eine angemessene Belüftung benötigt. Wenn die Öffnungen blockiert sind, wird der Projektor beschädigt. y Abbildung des Objektivversatzbereichs • LU960ST / LU960 Normale Projektionsposition Tisch/Frontprojektion Vertikaler Versatz Maximal 0,62V Höhe des projizierten Bildes Vertikaler Versatz Maximal 0,62V 0,24H 0,24H Deckenmontage/Frontprojektion Breite des projizierten Bildes Maximal 0,62V Vertikaler Versatz Höhe des projizierten Bildes...
LED-Anzeige y LED-Nutzung LED-Name Detaillierte Beschreibung Zeigt den Status der Ein-/Abschaltsequenz Orange : Ausgeschaltet (Grün + Rot) Betriebs-LED Grün : Eingeschaltet Blinken: Aufwärmung/Abschaltung und Kühlung / Fehler- code Zeigt den Temperaturstatus (Lüfterfehler, Überhitzung usw.) Temperaturstatus-LED Rot : Überhitzung Blinken: Fehlercode Zeigt den Lampenstatus (Lampenfehler, Lampenausbeute usw.) Lampenstatus-LED...
Seite 110
y Integrierte Meldungen Ein-/ Temp Licht Status und Beschreibung Austaste Grün Einbrennen ein Grün Grün Grün Einbrennen aus y Lampenfehlermeldungen Ein-/ Temp Licht Status und Beschreibung Austaste Lampe-1-Fehler im Normalbetrieb Lampe leuchtet nicht Blinkt y Temperaturfehlermeldungen Ein-/ Temp Licht Status und Beschreibung Austaste Lüfter-1-Fehler (die tatsächliche Lüftergeschwindigkeit entspricht nicht der gewünschten Geschwindigkeit)
RS-232-Befehl RS-232-Pinbelegung Seriell Seriell Kurz mit Pin 8 Kurz mit Pin 7 Erde Serieller RS-232-Anschluss mit gekreuztem Kabel Funktion Bedienung ASCII Power Write Power On <CR>*pow=on#<CR> Write Power Off <CR>*pow=off#<CR> Read Power Status <CR>*pow=?#<CR> Source Write COMPUTER/YPbPr <CR>*sour=RGB#<CR> Selection Write HDMI(MHL) <CR>*sour=hdmi#<CR>...
Seite 115
Funktion Bedienung ASCII Picture Setting Write Aspect Auto <CR>*asp=AUTO#<CR> Write Aspect Real <CR>*asp=REAL#<CR> Write Aspect 2.4:1 <CR>*asp=2.4#<CR> Read Aspect Status <CR>*asp=?#<CR> Write Vertical Keystone + <CR>*vkeystone=+#<CR> Write Vertical Keystone - <CR>*vkeystone=-#<CR> Write Set Vertical Keystone value <CR>* vkeystone=value#<CR> Read Vertical Keystone value <CR>*vkeystone=?#<CR>...
Seite 116
Funktion Bedienung ASCII Picture Setting Write Brilliant color + <CR>*BC=+#<CR> Write Brilliant color - <CR>*BC=-#<CR> Write Brilliant color set value <CR>*BC=value#<CR> Read Brilliant color status <CR>*BC=?#<CR> Write Auto(HDR) <CR>*hdr=auto#<CR> Write <CR>*hdr=sdr#<CR> Write HDR10 <CR>*hdr=hdr#<CR> Write <CR>*hdr=hlg#<CR> Read HDR status <CR>*hdr=?#<CR> Write Reset current picture settings <CR>*rstcurpicsetting#<CR>...
Seite 117
Funktion Bedienung ASCII Lamp Control Write Eco mode <CR>*lampm=eco#<CR> Write Dimming mode <CR>*lampm=dimming#<CR> Write Custom mode <CR>*lampm=custom#<CR> Write Light level for custom mode <CR>*lampcustom=value#<CR> Read Light level status for custom mode <CR>*lampcustom=?#<CR> Read Lamp Mode Status <CR>*lampm=?#<CR> Read Model Name <CR>*modelname=?#<CR>...
Seite 118
Funktion Bedienung ASCII Miscellaneous Read Remote Receiver Status <CR>*rr=?#<CR> Write AMX Device Discovery-on <CR>*amxdd=on#<CR> Write AMX Device Discovery-off <CR>*amxdd=off#<CR> Read AMX Device Discovery Status <CR>*amxdd=?#<CR> Read Mac Address <CR>*macaddr=?#<CR> Read Serial Number <CR>*serialnumber=?#<CR> Write High Altitude mode on <CR>*Highaltitude=on#<CR> Write High Altitude mode off <CR>*Highaltitude=off#<CR>...
Seite 119
Funktion Bedienung ASCII Color Read Primary Color Status <CR>*primcr=?#<CR> Calibration Write Hue + <CR>*hue=+#<CR> Write Hue - <CR>*hue=-#<CR> Write Set Hue value <CR>*hue=value#<CR> Read Get Hue value <CR>*hue=?#<CR> Write Saturation + <CR>*saturation=+#<CR> Write Saturation - <CR>*saturation=-#<CR> Write Set Saturation value <CR>*saturation=value#<CR>...
PJLink y PJLink-Protokoll Die Netzwerkfunktion dieses Projektors unterstützt PJLink-Klasse 1 und das PJLink-Protokoll kann zur Durchführung von Projektoreinstellungen und Statusabfragen von einem Computer genutzt werden. y Steuerbefehle Die folgende Tabelle listet die PJLink-Protokollbefehle auf, die zur Steuerung des Projektors genutzt werden können. •...
Seite 121
Parameter/ Befehl Steuerdetails Rückga- Anmerkung bestring Input selection 11 12 21 31 32 33 INST? LU960ST list query Projector name Returns the name set in [PROJECTOR NAME] of [NET- NAME? xxxxx query WORK SETUP] Manufacturer INF1? BenQ Returns manufacturer name...
Seite 122
Comando RS232 ................136 Assegnazione dei pin RS232 ................... 136 Porta seriale RS232 con un cavo crossover ............136 PJLink ........................143 Visitare il sito web di seguito per la versione più recente del manuale d'uso/della guida all'installazione. http://business-display.benq.com/ V1.00...
Notice Avviso sul laser Attenzione – l'uso di comandi, regolazioni o procedure diversi da quelli indicati potrebbero provocare l'esposizione a radiazioni pericolose. Non puntare il laser ed evitare che la luce laser sia diretta o riflessa verso altre persone o oggetti riflettenti.
Avviso sul raffreddamento Lasciare almeno 50 cm (19,7 pollici) di spazio attorno allo scarico dell’aria. Assicurarsi che nessun oggetto blocchi le prese d’aria entro 50 cm (19,7 pollici). Tenere lo scarico dell’aria ad almeno 1 di distanza dalle prese d’aria di altri proiettori. Scarico Presa dell’aria...
Seite 125
• Lasciare almeno 50 cm di spazio attorno allo scarico dell’aria. Minimo 50 cm Minimo 50 cm (19,69 pollici) (19,69 pollici) Minimo 50 cm (19,69 pollici) Minimo 100 cm (39,37 pollici) Minimo 50 cm (19,69 pollici) • Assicurarsi che le prese d’aria non riciclino l’aria calda dello scarico dell’aria. •...
Assicurarsi che la porta sia valida prima di inserire un telecomando cablato. Il telecomando potrebbe essere danneggiato se la porta non è valida, ad esempio se il telecomando cablato è collegato alla porta Trigger. Per ulteriori informazioni sull'aggiornamento del firmware tramite LAN, contattare il servizio BenQ.
Telecomando ON / OFF Fa passare il proiettore tra la modalità di standby e di accensione. KEYSTONE+/KEYSTONE- Correzione manuale della distorsione delle immagini provocata dalla proiezione inclinata. VOLUME +/VOLUME - Aumenta/diminuisce il volume del proiettore. QUICK INSTALL Visualizza il menu OSD Installazione rapida. MUTE Attiva e disattiva l’audio del proiettore.
Seite 129
OVERSCAN Premere per selezionare la modalità overscan. FREEZE Blocca l’immagine proiettata. LAMP MODE Premere per visualizzare il menu OSD per selezionare la modalità di illuminazione voluta. 3D MODE Premere per visualizzare il menu di impostazione 3D. INFO. Premere per visualizzare il menu INFORMAZIONI. LIGHT Premere per accendere l’illuminazione del telecomando.
Installazione Copriobiettivo/ Blocco obiettivo 1. Rimuovere il copriobiettivo prima di avviare. 2. Installare il blocco dell’obiettivo 3. Fissare con le viti, ma non stringere completamente 4. Regolare la messa a fuoco 5. Stringere le viti...
Projection table • LU960ST Il formato dello schermo è 16:10 e l’immagine proiettata è 16:10. Nota: Per ottimizzare la qualità di proiezione, si consiglia di proiettare immagini in un’area priva di scala di grigi. Formato immagine Distanza Diagonale Larghezza Altezza...
Seite 132
• L'installazione a soffitto deve essere effettuata da un professionista qualificato. Rivolgersi al rivenditore per ulteriori informazioni. Si consiglia di non installare il proiettore da soli. • Utilizzare il proiettore solo su una superficie solida e piana. Se il proiettore cade, possono verificarsi lesioni gravi e danni. • Non utilizzare il proiettore in un ambiente in cui si verificano temperature estreme. Il proiettore deve essere utilizzato a temperature comprese tra 41º Fahrenheit (5º Celsius) e 104º Fahrenheit (40º Celsius). • Se il proiettore viene esposto a umidità, polvere o fumo possono verificarsi danni allo schermo. • Non coprire le bocchette del proiettore. Per dissipare il calore, è necessaria una corretta ventilazione. Se le bocchette sono ostruite, possono verificarsi danni al proiettore. y Grafico Intervallo di spostamento dell’obiettivo • LU960ST / LU960 Normale posizione di proiezione Proiezione tavolo - frontale Spostamento verticale Max 0,62V Altezza dell'immagine proiettata Spostamento verticale Max 0,62V 0,24H 0,24H Proiezione soffitto - frontale...
y Utilizzo del LED Nome LED Descrizione dettagliata Visualizza lo stato della sequenza di accensione/spegnimento dell'alimentazione. Arancione: Spegnimento (Verde + Rosso) LED di alimentazione Verde: Accensione Lampeggiante: Riscaldamento/Spegnimento e raffreddamento/Co- dice di errore Visualizza lo stato termico (Guasto ventola, Surriscaldamento, ecc.) LED di stato della temperatura Rosso: Surriscaldamento...
Seite 134
y Messaggi burn-in Alime- Temp Light Stato e descrizione ntazione Verde Burn-in ON Verde Verde Verde Burn-in OFF y Messaggi di errore lampada Alime- Temp Light Stato e descrizione ntazione Rosso Errore Lamp1 durante funzionamento normale Rosso Lampada non accesa Lampeggiante y Messaggi di errore termico Alime-...
Seite 135
Alime- Temp Light Stato e descrizione ntazione Verde Lampeggi- Verde Errore corto sensore termico 2 ante Verde Verde Lampeggi- Lampeggi- IC termico 2 Errore connessione I2C ante ante Verde Rosso Rosso Errore temperatura 3 (temperatura sopra il limite) Rosso Verde Rosso Lampeggi- Errore apertura sensore termico 3...
Comando RS232 Assegnazione dei pin RS232 Seriale Seriale Corto con pin 8 Corto con pin 7 Terra Porta seriale RS232 con un cavo crossover Funzione Tipo Funzionamento ASCII Power Write Power On <CR>*pow=on#<CR> Write Power Off <CR>*pow=off#<CR> Read Power Status <CR>*pow=?#<CR>...
Seite 138
Funzione Tipo Funzionamento ASCII Audio Source Write Audio pass Through off <CR>*audiosour=off#<CR> Select Write Audio-Computer1 <CR>*audiosour=RGB#<CR> Write Audio-HDMI <CR>*audiosour=hdmi#<CR> Write Audio-HDMI2 <CR>*audiosour=hdmi2#<CR> Write DisplayPort <CR>*audiosour=dp#<CR> Write HDBaseT <CR>*audiosour=hdbaset#<CR> Read Audio pass Status <CR>*audiosour=?#<CR> Picture Mode Write Presentation <CR>*appmod=preset#<CR> Write sRGB <CR>*appmod=srgb#<CR>...
Seite 139
Funzione Tipo Funzionamento ASCII Picture Setting Write Aspect Auto <CR>*asp=AUTO#<CR> Write Aspect Real <CR>*asp=REAL#<CR> Write Aspect 2.4:1 <CR>*asp=2.4#<CR> Read Aspect Status <CR>*asp=?#<CR> Write Vertical Keystone + <CR>*vkeystone=+#<CR> Write Vertical Keystone - <CR>*vkeystone=-#<CR> Write Set Vertical Keystone value <CR>* vkeystone=value#<CR> Read Vertical Keystone value <CR>*vkeystone=?#<CR>...
Seite 140
Funzione Tipo Funzionamento ASCII Picture Setting Write Brilliant color + <CR>*BC=+#<CR> Write Brilliant color - <CR>*BC=-#<CR> Write Brilliant color set value <CR>*BC=value#<CR> Read Brilliant color status <CR>*BC=?#<CR> Write Auto(HDR) <CR>*hdr=auto#<CR> Write <CR>*hdr=sdr#<CR> Write HDR10 <CR>*hdr=hdr#<CR> Write <CR>*hdr=hlg#<CR> Read HDR status <CR>*hdr=?#<CR>...
Seite 141
Funzione Tipo Funzionamento ASCII Lamp Control Write Eco mode <CR>*lampm=eco#<CR> Write Dimming mode <CR>*lampm=dimming#<CR> Write Custom mode <CR>*lampm=custom#<CR> Write Light level for custom mode <CR>*lampcustom=value#<CR> Read Light level status for custom mode <CR>*lampcustom=?#<CR> Read Lamp Mode Status <CR>*lampm=?#<CR> Miscellaneous Read Model Name <CR>*modelname=?#<CR>...
Seite 142
Funzione Tipo Funzionamento ASCII Miscellaneous Read Remote Receiver Status <CR>*rr=?#<CR> Write AMX Device Discovery-on <CR>*amxdd=on#<CR> Write AMX Device Discovery-off <CR>*amxdd=off#<CR> Read AMX Device Discovery Status <CR>*amxdd=?#<CR> Read Mac Address <CR>*macaddr=?#<CR> Read Serial Number <CR>*serialnumber=?#<CR> Write High Altitude mode on <CR>*Highaltitude=on#<CR> Write High Altitude mode off <CR>*Highaltitude=off#<CR>...
Seite 143
Funzione Tipo Funzionamento ASCII Color Read Primary Color Status <CR>*primcr=?#<CR> Calibration Write Hue + <CR>*hue=+#<CR> Write Hue - <CR>*hue=-#<CR> Write Set Hue value <CR>*hue=value#<CR> Read Get Hue value <CR>*hue=?#<CR> Write Saturation + <CR>*saturation=+#<CR> Write Saturation - <CR>*saturation=-#<CR> Write Set Saturation value <CR>*saturation=value#<CR>...
5th byte Return 0 Indicates other errors, and 6th byte returns 0 - 2 Light source sta- LAMP? xxxxxxxxxxxx 1st number (1-5 digitals): Light source 1 runtime tus query Input selection 11 12 21 31 32 33 INST? LU960ST list query...
Seite 145
WORK SETUP] Manufacturer INF1? BenQ Returns manufacturer name name query Model name que- INF2? LU960ST Returns moder name Other informa- INF0? xxxxx Returns information such as version number tion queries Class information CLASS? Returns class for PJLink query...
Seite 146
Светодиодный индикатор ..............156 Размеры проектора .................159 Передача сигналов управления по RS-232 .........160 Назначение контактов RS-232 ................160 Последовательный порт RS-232 с перекрестным кабелем ......160 PJLink ........................167 Последняя версия руководства пользователя и руководства по установке доступна на веб-сайте ниже. http://business-display.benq.com/ V1.00...
Notice Примечание относительно лазера Внимание: использование элементов управления, регулировок или выполнение процедур, отличных от указанных в настоящем документе, может привести к опасному радиационному облучению. Не направляйте лазер на людей и следите, чтобы лазерный луч или его отражение не были направлены на других людей или отражающие объекты. Прямое...
Примечание относительно охлаждения Оставьте как минимум 50 см (19,7 дюйма) свободного пространства вокруг вентиляционных отверстий. На расстоянии 50 см (19,7 дюйма) от проектора не должно быть никаких предметов, блокирующих поступление воздуха. Выпускные отверстия должны находиться на расстоянии не менее 1 метра от впускных...
Seite 149
• Оставьте как минимум 50 см свободного пространства вокруг вентиляционных отверстий. Минимум 50 см Минимум 50 см (19,69 дюйма) (19,69 дюйма) Минимум 50 см (19,69 дюйма) Минимум 100 см (39,37 дюйма) Минимум 50 см (19,69 дюйма) • Удостоверьтесь, что во впускные отверстия не поступает нагретый воздух из выпускных...
Подключение источника аудиосигнала аудиокабелем. Внимание! Подключать проводной пульт ДУ допускается только к соответствующему порту. Пульт ДУ может быть поврежден при подключении к неподходящему порту, например, к триггерному выходу. За дополнительной информацией об обновлении встроенного ПО по LAN обращайтесь сервисный центр BenQ.
Remote control ON / OFF Переключение режимов ожидания и включения проектора. KEYSTONE+/KEYSTONE- Ручная коррекция искажений изображения, возникших в результате проекции под углом. VOLUME +/VOLUME - Увеличение/уменьшение громкости проектора. QUICK INSTALL На экран выводится меню Быстрая установка. MUTE Включение и выключение звука проектора. Кнопки...
Seite 153
OVERSCAN Нажмите для настройки нерабочей области FREEZE Стоп-кадр проецируемого изображения. LAMP MODE Нажмите для открытия экранного меню и выбора необходимого режима света. 3D MODE Нажмите для открытия меню настройки 3D. INFO. Нажмите для вызова меню «ИНФОРМАЦИЯ». LIGHT Нажмите для включения подсветки пульта ДУ. CLEAR Очистка...
Установка Крышка объектива / Замок объектива 1. Перед тем, как убрать в чехол, снимите крышку объектива. 2. Установите замок объектива 3. Закрепите винтами, не затягивайте до упора 4. Настройте фокусировку изображения 5. Затяните винты...
Projection table • LU960ST Соотношение сторон экрана составляет 16:10, а проецируемого изображения – 16:10. Примечание: Для оптимизации качества проецирования рекомендуется проецировать изображения в зоне, не имеющей оттенков серого. Размер изображения Расстояние Диагональ Ширина Высота Минимальное Среднее значение Максимальное проекционное проекционное...
Seite 156
• Визуализированные инструкции доступны на веб-сайте калькулятора BenQ по адресу http://projectorcalculator.benq.com/ • Потолочный монтаж должен выполняться квалифицированным специалистом. Обратитесь к своему дилеру за дополнительной информацией. Не рекомендуется устанавливать проектор самостоятельно. • Используйте проектор только на твердой, ровной поверхности. Падение проектора может стать причиной тяжелой травмы или повреждения. • Не эксплуатируйте проектор в среде, в которой могут создаться экстремальные температуры. Эксплуатируйте проектор при температурах от 5 до 40 °С. • Воздействие на проектор влаги, пыли или дыма может вызвать повреждение экрана. • Не закрывайте вентиляционные отверстия проектора. Для рассеивания тепла необходима надлежащая вентиляция. Закрытие вентиляционных отверстий приведет к повреждению проектора. • Схема диапазона смещений объектива • LU960ST / LU960 Стол — фронтальная проекция Нормальное положение проекции Вертикальное смещение Макс. 0,62 В 1 В Высота проецируемого изображения Вертикальное смещение Макс. 0,62 В 0,24 Ш 1 Ш 0,24 Ш Потолок — фронтальная проекция Ширина проецируемого...
Светодиодный индикатор y LED Usage LED Name Detailed Description Отображение состояния последовательности вкл./ выкл. питания Оранжевый: Выключение (Зеленый + Красный) Индикатор питания Зеленый: Включение Мигает: Прогревание/ Завершение работы и охлаждение/ Код ошибки Отображение теплового состояния (сбой вентилятора, перегрев и т.д.) Индикатор...
Seite 158
y Сообщения приработки Темпер- Подсв- Питание Состояние и описание атура етка Зеленый Приработочные испытания вкл. Зеленый Зеленый Зеленый Приработочные испытания выкл. y Сообщения ошибок лампы Темпер- Подсв- Питание Состояние и описание атура етка Ошибка Лампы 1 при работе в нормальных Красный...
Seite 159
Темпер- Подсв- Питание Состояние и описание атура етка Зеленый Зеленый Ошибка подключения Термального IC №2 I2C Мигает Мигает Ошибка Температуры 3 (превышены Зеленый Красный Красный температурные ограничения) Красный Зеленый Красный Ошибка открытия Термодатчика 3 Мигает Зеленый Красный Зеленый Короткое замыкание Термодатчика 3 Зеленый...
Передача сигналов управления по RS-232 Назначение контактов RS-232 № Последовательный № Последовательный Закорочен с контактом 8 Закорочен с контактом 7 Заземление Последовательный порт RS-232 с перекрестным кабелем Функция Тип Порядок работы ASCII Power Write Power On <CR>*pow=on#<CR> Write Power Off <CR>*pow=off#<CR>...
Функция Тип Порядок работы ASCII Audio Source Write Audio pass Through off <CR>*audiosour=off#<CR> Select Write Audio-Computer1 <CR>*audiosour=RGB#<CR> Write Audio-HDMI <CR>*audiosour=hdmi#<CR> Write Audio-HDMI2 <CR>*audiosour=hdmi2#<CR> Write DisplayPort <CR>*audiosour=dp#<CR> Write HDBaseT <CR>*audiosour=hdbaset#<CR> Read Audio pass Status <CR>*audiosour=?#<CR> Picture Mode Write Presentation <CR>*appmod=preset#<CR> Write sRGB <CR>*appmod=srgb#<CR>...
Seite 163
Функция Тип Порядок работы ASCII Picture Setting Write Aspect Auto <CR>*asp=AUTO#<CR> Write Aspect Real <CR>*asp=REAL#<CR> Write Aspect 2.4:1 <CR>*asp=2.4#<CR> Read Aspect Status <CR>*asp=?#<CR> Write Vertical Keystone + <CR>*vkeystone=+#<CR> Write Vertical Keystone - <CR>*vkeystone=-#<CR> Write Set Vertical Keystone value <CR>* vkeystone=value#<CR> Read Vertical Keystone value <CR>*vkeystone=?#<CR>...
Seite 164
Функция Тип Порядок работы ASCII Picture Setting Write Brilliant color + <CR>*BC=+#<CR> Write Brilliant color - <CR>*BC=-#<CR> Write Brilliant color set value <CR>*BC=value#<CR> Read Brilliant color status <CR>*BC=?#<CR> Write Auto(HDR) <CR>*hdr=auto#<CR> Write <CR>*hdr=sdr#<CR> Write HDR10 <CR>*hdr=hdr#<CR> Write <CR>*hdr=hlg#<CR> Read HDR status <CR>*hdr=?#<CR>...
Seite 165
Функция Тип Порядок работы ASCII Lamp Control Write Eco mode <CR>*lampm=eco#<CR> Write Dimming mode <CR>*lampm=dimming#<CR> Write Custom mode <CR>*lampm=custom#<CR> Write Light level for custom mode <CR>*lampcustom=value#<CR> Read Light level status for custom mode <CR>*lampcustom=?#<CR> Read Lamp Mode Status <CR>*lampm=?#<CR> Miscellaneous Read Model Name <CR>*modelname=?#<CR>...
Seite 166
Функция Тип Порядок работы ASCII Miscellaneous Read Remote Receiver Status <CR>*rr=?#<CR> Write AMX Device Discovery-on <CR>*amxdd=on#<CR> Write AMX Device Discovery-off <CR>*amxdd=off#<CR> Read AMX Device Discovery Status <CR>*amxdd=?#<CR> Read Mac Address <CR>*macaddr=?#<CR> Read Serial Number <CR>*serialnumber=?#<CR> Write High Altitude mode on <CR>*Highaltitude=on#<CR>...
Seite 167
Функция Тип Порядок работы ASCII Color Read Primary Color Status <CR>*primcr=?#<CR> Calibration Write Hue + <CR>*hue=+#<CR> Write Hue - <CR>*hue=-#<CR> Write Set Hue value <CR>*hue=value#<CR> Read Get Hue value <CR>*hue=?#<CR> Write Saturation + <CR>*saturation=+#<CR> Write Saturation - <CR>*saturation=-#<CR> Write Set Saturation value <CR>*saturation=value#<CR>...
PJLink y Протокол PJLink Сетевая функция данного проектора поддерживает PJLink класса 1, а протокол PJLink может использоваться для выполнения операций по настройке проектора и запросу состояния проектора с компьютера. y Сигналы управления В следующей таблице представлены команды протокола PJLink, которые можно использовать...
Seite 169
Light source sta- LAMP? xxxxxxxxxxxx 1st number (1-5 digitals): Light source 1 runtime tus query Input selection 11 12 21 31 32 INST? LU960ST list query 33 34 Projector name Returns the name set in [PROJECTOR NAME] of NAME? xxxxx query...
Seite 170
프로젝터 크기 ................... 183 RS232 명령 ..................184 RS232 핀 할당 ......................184 크로스오버 케이블이 달린 RS232 직렬 포트 ............184 PJLink ........................191 한 국 어 사용 설명서 / 설치 가이드의 최종 버전을 보려면 아래의 웹사이트를 방문하십시오 . http://business-display.benq.com/ V1.00...
Notice 레이저에 관한 참고사항 주의 - 여기에 지정되지 않은 방식으로 절차를 제어 , 조정 또는 수행할 경우 , 유해 방사선에 노출될 수 있습니다 . 레이저를 가리키거나 레이저 광선이 다른 사람 또는 반사체를 향하거나 반사하지 않도록 주 의하십시오 . 직사광선이나 산란광은 눈과 피부에 유해할 수 있습니다 . 제공된...
냉각 관련 참고사항 배기구 주변에 적어도 50 cm (19.7 in) 의 간격을 두십시오 . 50 cm (19.7 in) 이내에 공기 유입 을 차단하는 물체가 없도록 하십시오 . 다른 프로젝터의 공기 유입구와 적어도 1 m 떨어진 곳에 공기 배출구가 오도록 하십시오 . 공기...
Seite 173
• 배기구 주변에 적어도 50 cm 의 간격을 두십시오 . 최소 50 cm 최소 50 cm (19.69 in) (19.69 in) 최소 50 cm (19.69 in) 최소 100 cm (39.37 in) 최소 50 cm (19.69 in) • 공기 유입구로 배기구의 뜨거운 공기가 재순환되지 않도록 하십시오 . •...
포장 내용물 기본 제공 품목 방지 캡이 있는 프로젝터 리모컨 배터리 설치 안내서 전원 케이블 규정 정보 사양 LU960ST LU960 1- 칩 DMD 프로젝션 시스템 1920*1200 픽셀 , 16:10 원시 해상도 한 광원 레이저 다이오드 국 0.77 ~ 0.84 1.13 ~ 1.70 투사율...
유선 리모컨을 끼우기 전에 올바른 포트인지 확인하십시오 . 예를 들어 유선 리모컨을 트리거 출력 포트에 연결 하는 식으로 맞지 않는 포트에 끼울 경우 리모컨이 손상될 수 있습니다 . LAN 을 통한 펌웨어 업그레이드에 대한 자세한 내용은 BenQ 서비스 센터로 문의하십시오 .
리모컨 ON / OFF 프로젝터를 대기 모드 또는 켜짐 사이에서 전환합니다 . KEYSTONE+/KEYSTONE- 영사 각도 때문에 사다리꼴이 된 이미지를 수동으로 보정할 수 있습니 다 . VOLUME +/VOLUME - 프로젝터 볼륨을 증가 / 감소시킵니다 . QUICK INSTALL 빠른 설치 OSD 메뉴를 표시합니다 . MUTE 프로젝터를...
Seite 177
OVERSCAN 눌러 오버스캔 모드를 선택합니다 . FREEZE 영사 이미지를 정지시킵니다 . LAMP MODE 눌러 원하는 LIGHT 모드를 선택할 수 있는 OSD 메뉴를 표시합니다 . 3D MODE 눌러 3D 설정 메뉴를 표시합니다 . INFO. 눌러 정보 메뉴를 표시합니다 . LIGHT 눌러 리모컨의 백라이트를 엽니다 . CLEAR 모든...
영사 거리 • LU960ST 화면비는 16:10 이며 투사 이미지는 16:10 입니다 . 참고 : 투사 품질을 최적화하기 위해 그레이스케일이 없는 영역에 이미지를 투사할 것을 권정합니다 . 이미지 크기 거리 최소 거리 - 와이드 최대 거리 - 텔레 대각선 너비 높이...
Seite 180
화면 화면 참고 : • 보다 시각화된 지침을 보려면 BenQ calculator 웹사이트 http://projectorcalculator.benq.com/ 로 이동하십시오 . • 천장 설치는 자격이 있는 전문가가 설치해야 합니다 . 자세한 내용은 가까운 대리점에 문의하십시오 . 사용자 가 직접 프로젝터를 설치하지 마십시오 . • 프로젝터는 견고하고 평평한 표면에서만 사용하십시오 . 프로젝터가 떨어지면 중상을 입거나 프로젝터가 손...
RS232 명령 RS232 핀 할당 번호 직렬 번호 직렬 핀 8 에서 단락 핀 7 에서 단락 접지 크로스오버 케이블이 달린 RS232 직렬 포트 ASCII 기능 유형 작동 Power Write Power On <CR>*pow=on#<CR> Write Power Off <CR>*pow=off#<CR> Read Power Status <CR>*pow=?#<CR>...
Seite 186
ASCII 기능 유형 작동 Audio Source Write Audio pass Through off <CR>*audiosour=off#<CR> Select Write Audio-Computer1 <CR>*audiosour=RGB#<CR> Write Audio-HDMI <CR>*audiosour=hdmi#<CR> Write Audio-HDMI2 <CR>*audiosour=hdmi2#<CR> Write DisplayPort <CR>*audiosour=dp#<CR> Write HDBaseT <CR>*audiosour=hdbaset#<CR> Read Audio pass Status <CR>*audiosour=?#<CR> Picture Mode Write Presentation <CR>*appmod=preset#<CR> Write sRGB <CR>*appmod=srgb#<CR>...
Seite 187
ASCII 기능 유형 작동 Picture Setting Write Aspect Auto <CR>*asp=AUTO#<CR> Write Aspect Real <CR>*asp=REAL#<CR> Write Aspect 2.4:1 <CR>*asp=2.4#<CR> Read Aspect Status <CR>*asp=?#<CR> Write Vertical Keystone + <CR>*vkeystone=+#<CR> Write Vertical Keystone - <CR>*vkeystone=-#<CR> Write Set Vertical Keystone value <CR>* vkeystone=value#<CR> Read Vertical Keystone value <CR>*vkeystone=?#<CR>...
Seite 188
ASCII 기능 유형 작동 Picture Setting Write Brilliant color + <CR>*BC=+#<CR> Write Brilliant color - <CR>*BC=-#<CR> Write Brilliant color set value <CR>*BC=value#<CR> Read Brilliant color status <CR>*BC=?#<CR> Write Auto(HDR) <CR>*hdr=auto#<CR> Write <CR>*hdr=sdr#<CR> Write HDR10 <CR>*hdr=hdr#<CR> Write <CR>*hdr=hlg#<CR> Read HDR status <CR>*hdr=?#<CR>...
Seite 189
ASCII 기능 유형 작동 Lamp Control Read Lamp Hour <CR>*ltim=?#<CR> Write Normal mode <CR>*lampm=lnor#<CR> Lamp Control Write Eco mode <CR>*lampm=eco#<CR> Write Dimming mode <CR>*lampm=dimming#<CR> Write Custom mode <CR>*lampm=custom#<CR> Write Light level for custom mode <CR>*lampcustom=value#<CR> Read Light level status for custom mode <CR>*lampcustom=?#<CR>...
Seite 190
ASCII 기능 유형 작동 Miscellaneous Read Remote Receiver Status <CR>*rr=?#<CR> Write AMX Device Discovery-on <CR>*amxdd=on#<CR> Write AMX Device Discovery-off <CR>*amxdd=off#<CR> Read AMX Device Discovery Status <CR>*amxdd=?#<CR> Read Mac Address <CR>*macaddr=?#<CR> Read Serial Number <CR>*serialnumber=?#<CR> Write High Altitude mode on <CR>*Highaltitude=on#<CR> Write High Altitude mode off <CR>*Highaltitude=off#<CR>...
Seite 191
ASCII 기능 유형 작동 Color Read Primary Color Status <CR>*primcr=?#<CR> Calibration Write Hue + <CR>*hue=+#<CR> Write Hue - <CR>*hue=-#<CR> Write Set Hue value <CR>*hue=value#<CR> Read Get Hue value <CR>*hue=?#<CR> Write Saturation + <CR>*saturation=+#<CR> Write Saturation - <CR>*saturation=-#<CR> Write Set Saturation value <CR>*saturation=value#<CR>...
5th byte Return 0 Indicates other errors, and 6th byte returns 0 - 2 Light source LAMP? xxxxxxxxxxxx 1st number (1-5 digitals): Light source 1 runtime status query Input selection 11 12 21 31 32 INST? LU960ST list query 33 34...
Seite 193
WORK SETUP] Manufacturer INF1? BenQ Returns manufacturer name name query Model name que- INF2? LU960ST Returns moder name Other informa- INF0? xxxxx Returns information such as version number tion queries Class information CLASS? Returns class for PJLink query 참고...
Seite 211
機能 タイプ 操作 ASCII Picture Setting Write Aspect Auto <CR>*asp=AUTO#<CR> Write Aspect Real <CR>*asp=REAL#<CR> Write Aspect 2.4:1 <CR>*asp=2.4#<CR> Read Aspect Status <CR>*asp=?#<CR> Write Vertical Keystone + <CR>*vkeystone=+#<CR> Write Vertical Keystone - <CR>*vkeystone=-#<CR> Write Set Vertical Keystone value <CR>* vkeystone=value#<CR> Read Vertical Keystone value <CR>*vkeystone=?#<CR>...
Seite 212
機能 タイプ 操作 ASCII Picture Setting Write Brilliant color + <CR>*BC=+#<CR> Write Brilliant color - <CR>*BC=-#<CR> Write Brilliant color set value <CR>*BC=value#<CR> Read Brilliant color status <CR>*BC=?#<CR> Write Auto(HDR) <CR>*hdr=auto#<CR> Write <CR>*hdr=sdr#<CR> Write HDR10 <CR>*hdr=hdr#<CR> Write <CR>*hdr=hlg#<CR> Read HDR status <CR>*hdr=?#<CR>...
Seite 213
機能 タイプ 操作 ASCII Miscellaneous Read Model Name <CR>*modelname=?#<CR> Read System F/W Version <CR>*sysfwversion=?#<CR> Read Scaler F/W Version <CR>*scalerfwversion=?#<CR> Read Lan F/W Version <CR>*lanfwversion=?#<CR> Read MCU F/W Version <CR>*mcufwversion=?#<CR> Write Blank On <CR>*blank=on#<CR> Write Blank Off <CR>*blank=off#<CR> Read Blank Status <CR>*blank=?#<CR>...
Seite 214
機能 タイプ 操作 ASCII Color Write Tint + <CR>*tint=+#<CR> Calibration Write Tint - <CR>*tint=-#<CR> Write Set Tint value <CR>*tint=value#<CR> Read Get Tint value <CR>*tint=?#<CR> Write Set gamma value <CR>*gamma=value#<CR> Read Gamma value status <CR>*gamma=?#<CR> Write Set HDR Brightness value <CR>*hdrbri=value#<CR> Read Get HDR Brightness value <CR>*hdrbri=?#<CR>...
Seite 215
機能 タイプ 操作 ASCII Service Read Error Code report <CR>*error=report#<CR> Read FAN 1 speed <CR>*fan1=?#<CR> Read FAN 2 speed <CR>*fan2=?#<CR> Read FAN 3 speed <CR>*fan3=?#<CR> Read FAN 4 speed <CR>*fan4=?#<CR> Read FAN 5 speed <CR>*fan5=?#<CR> Read FAN 6 speed <CR>*fan6=?#<CR> Read FAN 7 speed <CR>*fan7=?#<CR>...
Light source sta- LAMP? xxxxxxxxxxxx 1st number (1-5 digitals): Light source 1 runtime tus query Input selection 11 12 21 31 32 INST? LU960ST list query 33 34 Projector name Returns the name set in [PROJECTOR NAME] of [NET- NAME? xxxxx query...
Seite 217
コマンド 備考 詳細 戻り文字列 Manufacturer INF1? BenQ Returns manufacturer name name query Model name que- INF2? LU960ST Returns moder name Other informa- INF0? xxxxx Returns information such as version number tion queries Class information CLASS? Returns class for PJLink query 注...
