ELECTRICAL SAFETY

1. Ensure the rated voltage shown on the rating label corresponds with
the voltage of the power supply.
2. Do not operate any appliance with a damaged power cord or plug,
when the appliance malfunctions or has been damaged in any manner.
3. Protect the power cord against damages. Do not let it hang over
sharp edges, do not squeeze or bend it. Keep the power cord away
from hot surfaces and ensure that nobody can trip over it.
4. Do not open the housing under any circumstances. Do not insert fin-
gers or foreign objects in any opening of the appliance and do not
obstruct the air vents.
5. Protect the appliance against heat. Do not place close to open
flames or heat sources such as stoves or heating appliances.
24

THE APPLIANCE

23
22
21
20
19
18
17
16
15
14
27
26
25
24
1. Bean hopper lid 12. Tamper
2. Bean hopper 13. Brewing head
3. Grinding wheel 14. Coffee powder outlet
4. Cup warming plate 15. Drip tray
5. Water tank lid 16. Floater
6. Water tank 17. Drip plate
7. Control knob 18. Portafilter
8. Coffee/Hot water outlet 19. Single cup filter
9. Power cord with power plug 20. Double cup filer
10. Milk jug 21. Cleaning pin
11. Steam wand 22. Cleaning brush
1
2
4
3
5
6
7
8
9
10
11
12
13
28
29
30
31
32
23. Accessory box
24. Clean/Descale indicator
25. Grinding button (Double cup)
26. Grinding button (Single cup)
27. Power button
28. Program button
29. Double cup button
30. Single cup button
31. Steam/hot water indicator
32. Pressure gauge
