Marzocchi Shock absorber setting -
LEONCINO 800 TRAIL
SHOCK AB SORB ER SETTING
Leoncino 800 TRAIL
SHOCK AB SORB ER REB OUND
Comfort O pen 3 turn f rom completely closed
Sport O pen 2 turn f rom completely closed
Fu ll load ed O pen 2 turn f rom completely
closed
Completely clos ed
ma im m re o nd , the scre is completel
closed cloc ise
SPRING PRE- LOAD
ll open t rning an� cloc
Comfort
Sport 2 turns f rom f ully open
Fu ll load ed 10 turns f rom f ully open
Completely open
minimum preload , f ully open turning
an�-cloc ise
NOTICE
The suggested adjustments are indica-
tive valid for one driver and / or passen-
ger weighing 75 kg.
Marzocchi front fork setting -
LEONCINO 800 TRAIL
FRONT FORK ADJUSTMENT
Leoncino 800 TRAIL
FRONT FORK EXTENSION ADJUSTMENT
( righ t s id e front fork )
Comfort
open 3 turn f rom completely close d
Sport
open 2 , 5 turn f rom completely close d
Fu ll load ed
open 3 turn f rom completely close d
Completely clos ed
max imum rebound , th e screw is completely
closed clock w ise.
FRONT FORK COMPRESSION ADJUSTMENT
(le side ront or )
Comfort open 3 turn f rom completely close d
ise
Sport open 2 turn f rom completely close d
Fu ll load ed open 3 turn f rom completely close d
Completely clos ed
max imum rebound , th e screw is completely
closed clock w ise.
SPRING PRELOAD
2 turns f rom f ully open
Comfort
Sport
5 turns f rom f ully open
Fu ll load ed
2 turns f rom f ully open
Fu lly open
minim m preload , ll open an� cloc
3 - 17
Instrument and control functions
SPRING
PRELOAD
SPRING
PRELOAD
LEFT FRONT FORK
ise
EXTENSION
ADJUSTMENT
EN
COMPRESSION
ADJUSTMENT
SPRING REBOUND
ADJUSTMENT
PRELOAD
RIGHT FRONT FORK
3
