If your system is not up to date, follow the steps in chapter 3.2.2.1 to update it. For the update procedure to work
the CIRCLE obviously needs to be connected to the internet. You may possibly also have to disable the firewall
temporarily to make the update server reachable from the device.
The options regarding ACCESS 1 and ACCESS 2 then become available. You will find them under SYSTEM
SETTINGS SIP (for the DTMF tone), under SYSTEM SETTINGS
The following table explains what ACCESS 1 and ACCESS 2 stand for:
ACCESS 1
EVENT ACCESS GRANTED EVENT
TRIGGERED BY NFC (access granted event)
KEYPAD CODE (access granted event)
DTMF 1 (default 42)
OUTPUT Built-in relay and one or both relays of the
I/O module
So, to further explain the table: the only fixed relation is between ACCESS 1 and the ACCESS GRANTED event
which is triggered by several different user interactions.
If you have an I/O module connected to the CIRCLE (any model and version), you can freely configure the two
relays to
DIVUS CIRCLE user manual .
DOOR LOCK RELAY to configure the built-in relay
ACCESS 2
ACCESS 2 EVENT
DTMF 2 (DEFAULT 43)
Any output configured for ACCESS 2 in the
I/O module(s) configuration
