Event 1 -4
Save the changes with the Save button when done.
6.2

I/O MODULE OUTPUT FUNCTION CONFIGURATION

To configure a function, click the pencil icon next to it in the I/O Modules settings page.
Basically, you can choose the way an output is switched, what event(s) should trigger it and whether the action
should involve a timer or not.
These are the options:
Description Use this field to add a description/name to the output function
Output Type Choose between monostable and bistable
Choose whether you need a timer and, if so, which one. The options will show a graph
Timer Type explaining the way they work if you select one. The timer function is enabled only if the
Output Type is monostable. See descriptions below.
Timer Duration
Choose one of the available events as trigger for an output. These assignments are
then available when configuring the single output functions of the I/O module. The
choices are:
•
Access 1
•
Movement
• Night
•
Access 2
•
Ringing
DIVUS CIRCLE user manual .
in seconds
60
