support@nextlevelracing.com
Repeat
on Other
Side
13
Install 2 x T-Nuts into the inside channels of both Wheel Posts. Red dots show T-Nuts placement.
)
A
Felt Pads
Note: Use level provided. Wheel Deck
must be kept flat and level during installation
to avoid skewing.
14
A) Remove protective layer on the Sticky Felt Pads and stick them on to the Wheel Deck to prevent scratching when adjusting.
B) Align the Wheel Deck with the T-Nuts previously installed in Step 13. Bolt through and secure with 4 x M8 Bolts and Washers.
ADJUSTMENT RANGE
Loosen the Bolts securing the Wheel Posts to the Base. Adjust to the desired position and tighten the Bolts to lock in place.
15
Loosen the Bolts securing the Wheel Deck to the Wheel Posts. Adjust to the desired height and angle using the alignment lines
as a guide, tighten the Bolts to secure the Wheel Deck in place.
PARTS:
• • 4 x T-Nuts
PARTS:
)
B
• • 4 x M8 16mm Bolts
• • 4 x M8 Washers
• • 2 x Sticky Felt Pads
(90mm x 10mm)
• • Wheel Deck
PARTS:
• • NIL
14
OUTSIDE VIEW
(
)
PRE-DRILLED HOLE
(
)
LEFT
(
)
PRE-DRILLED HOLE
(
)
RIGHT
16
Install 3 x T-Nuts into the top channel and 1 x T-Nut into the outside channel of the Left Pedal Arm.
Repeat the same steps for the Right Pedal Arm.
Note: For Shorter Users Please Skip
to STEPS 18 and 19.
17
Align the through hole on the Pedal Arms with the hole on the Upright Connection Plates. Bolt
through and secure with 2 x M8 Bolts, Washers, Square Washers and Flange Nuts.
ALTERNATE PEDAL INSTALLATION
(
)
FOR SHORTER USERS
(
PRE-DRILLED HOLE
(
PRE-DRILLED HOLE
)
(
)
RIGHT
18
Install 1 x T-Nut into the outside channel of each Pedal Arm.
Video Instruction: bit.ly/nlrbuild
PARTS:
TOP VIEW
• • 8 x T-Nuts
• • Pedal Arms
PARTS:
• • 2 x M8 60mm Bolts
• • 2 x M8 Washers
• • 2 x M8 Flange Nuts
• • 2 x Square Washers
PARTS:
• • 2 x T-Nuts
)
(
)
LEFT
• • 2 x Pedal Arms
15
