Function and device overview

The device may only be operated within residential buildings.
Using the device for any purpose other than that described in this
operating manual does not fall within the scope of intended use and
shall invalidate any warranty or liability.
3 Function and device overview
The Homematic IP Wall Thermostat offers time-controlled regulation of
your conventional radiators with Homematic IP Radiator Thermostats
or your floor heating in connection with Homematic IP Floor Heating
Actuators according to individually tailored heating phases.
The wall thermostat serves to measure the temperature in a room. The data
is cyclically transmitted to a radiator thermostat or floor heating actuator
in order to regulate the room temperature precisely. In connection with
a Homematic IP Window and Door Contact the temperature is reduced
automatically during ventilation.
You can directly connect the wall thermostat to one or more Homematic
IP devices (e.g. the Homematic IP Radiator Thermostat – basic) and
adjust it to your personal settings. Alternatively, you can control the wall
thermostat in connection with a Homematic IP Access Point comfortably
via the free smartphone app.
Thanks to battery operation and radio communication, the device is
highly flexible where mounting and selecting a mounting location are
concerned.
Device overview (see figure 1):
(A) Electronic unit (thermostat)
(B) Display
(C) System button (pairing button and LED)
(D) Minus button
