Connection with the mains

Connect the device to the mains with the enclosed power supply cable.
The occupation of the connection-cables is as follows:
Cable Pin
Brown Live
Blue Neutral
Yellow/Green Earth
The earth has to be connected!
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC-
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.
Lighting effects must not be connected to dimming-packs.

OPERATION

After you connected the effect to the mains, the DJ-LED Head Wash TCL starts running. During the Reset,
the motors are trimmed and the device is ready for use afterwards.

Stand Alone operation

In the Stand Alone mode, the DJ-LED Head Wash TCL can be used without controller. You can do without a
controller as the DJ-LED Head Wash TCL features a built-in microphone, which provides automatic sound
control.
Disconnect the DJ-LED Head Wash TCL from the controller and select the desired "Master Mode".

Master/Slave-operation

Connect the master and slave-devices and adjust the settings as desribed above.

DMX-controlled operation

You can control the projectors individually via your DMX-controller. Every DMX-channel has a different
occupation with different features.

Addressing

The Control Board allows you to assign the DMX fixture address, which is defined as the first channel from
which the DJ-LED Head Wash TCL will respond to the controller.
Please, be sure that you don't have any overlapping channels in order to control each DJ-LED Head Wash
TCL correctly and independently from any other fixture on the DMX data link.
If two, three or more DJ-LED Head Wash TCL are addressed similarly, they will work similarly.
For address setting, press the Mode-button until the display shows „A.001" and set the desired address via
the Up/Down-buttons.
Controlling:
After having addressed all DJ-LED Head Wash TCL, you may now start operating these via your lighting
controller.
