Optional

As an option, you can also install a commercially-available overvoltage protection in the
Fronius DC Box 60/12.

Technical Data

Max. input voltage in no-load operation
Max. input current
Max. input current per fuse holder
Max. number of strings (with integrated module fuse)
Max. cable cross section for terminals on the solar module side
Max. cable cross section for terminals on the inverter side
Screw joint for cable attachment to the solar module side
Screw joint for cable attachment to the inverter side
Protection type
Protection class
Ambient conditions
Dimensions (without screw joints)
Weight
Abbreviations
DC cable 'OUT'
and Descriptions
Used
DC cable 'IN'
42
DC output cable from Fronius DC Box 60/12 to inverter.
The polarity of the DC cable 'OUT' depends on how the solar
module strings are connected to the Fronius DC Box 60/12..
Solar module strings from the solar modules to the Fronius DC
Box 60/12.
Each solar module string has one DC+ cable and one
DC- cable.
850 V
60 A
20 A
12
6 mm²
95 mm²
M16
M32
IP 55
II
-25 °C - +60 °C
-13 °F - +140 °F
500 x 350 x 145 mm
19.7 x 13.8 x 5.7 in.
5,9 kg
13.01 lbs.
