Electrisch schema / Electrical scheme / Schéma électrique / Schaltplan
MANUAL Knob
Connection for
manual ignition
Thermocouple
Combination Control
Interrupter Block
Ignition Cable
Receiver

Battery Compartment

Main Valve
Knob
ON/OFF Switch (optional)
OFF
ON
8 Wire Cable
Thermo Current Cable #2
or ON/OFF Switch with
Soldered Cable
Thermo Current Cable #1
RF Antenna
57
