13.4.1.2 Kennzeichnungen
8 POINT TEXT SIZE
USE TEMPOSONICS LOGO ARTWORK
Temposonics, LLC
3001 Sheldon Dr.
Cary, NC 27513
Model No:
Modèle No:
Serial No:
Numéro de série:
Date :
FM18CA0122X
FM
C
INTRINSICALLY SAFE
APPROVED
CL. I, Div. 1, GR. ABCD
CL. I, Zone 0, Ex ia IIC T4 Ga
INDICATES CRITICAL DIMENSIONS.
Ta = -50°C to +71°C ; IP65
when connected in accordance with FM approved
installation drawing # 651543-2
lorsqu'il est connecté en conformité avec FM approuvé
le plan d'installation # 651543-2
WARNING: REFER TO INSTALLATION DRAWING FOR CAUTION/WARNINGS
SEE PRINT REFERENCE CHART
AVERTISSEMENT : se référer au schéma d'installation à la prudence / AVERTISSEMENTS
USE TEMPOSONICS LOGO ARTWORK
Abb. 31: FMC-Kennzeichnung Eigensicherheit, Modbus und DDA, NEMA-Gehäuse
