Proper use

The device is intended for trimming large
branches and limbs. It is not designed for
extensive sawing work, felling trees or cut-
ting materials other than wood.
The device is intended for use in residenti-
al applications.
This device is not intended for commercial
use. Commercial use will invalidate the gu-
arantee. Any other use that is not expressly
permitted in these instructions may result in
damage to the device and pose a serious
hazard to the user.
The equipment is designed for use by
adults. Adolescents over the age of 16
may use the device only under supervi-
sion. Local regulations may specify an age
limit for the user. Do not use the device in
the rain.
The operator or user is responsible for ac-
cidents or damage to other people or their
property.
The manufacturer is not liable for damages
caused by unspecified use or incorrect
operation.
The device is part of the Parkside
X 20 V TEAM series and can be opera-
ted using Parkside X 20 V TEAM series
batteries. The batteries may only be
charged using chargers from the Parkside
X 20 V TEAM series.

General Description

The illustration of the principal
functioning parts can be found
on the front and back foldout
pages.

Scope of delivery

- Cordless pole-mounted pruner (2 parts)
- Allen key (4 mm)
- Carrying strap
- Blade encasing
- 100 cm³ Bio chain oil
- Operating instructions
Battery and charger are not
included.
A

Overview

1 Blade bar
2 Saw chain
3 Wing nut
4 Ring
5 Sprocket cover
6 Coupling nut
7 Tubular shaft
8 Eyelet
9 Push-fit lock
10 Carrying strap
11 Rechargeable battery
12 Storage for Allen key
13 On/Off switch
14 Handle
15 Safety switch
16 Quick-release lever
17 Additional handle
18 Locking mechanism of the telescopic
extension
19 Motor head
20 Bio chain oil
21 Allen key
22 Blade encasing
23 Oil passage
24 Coach screw
25 Chain sprocket
26 Threaded coupling
27 Extension arm
28 Lug at the extension arm
29 Oil tank cover
30 Oil level indicator
31 Locking button
