Instructions
Annex - A
Technical data (English)
Name plate
A
B
C
D
E
Fluid Group 1 & 2
F
PED Category II
G
Application MBP
H
PS -1/32 bar
HP
I
PS -1/21.5 bar
LP
J
PT 32 bar
K o
TS -30/ 63 C
HP Switch Pressure 31 bar
Year of Mfg. 2021
L
PRV Setting 34.5 bar
089
Only for Norway 0045 0879
Address - Danfoss Ltd., 22 Wycombe End, HP9 1NB, GB
Імпортер:ТОВ з іі "Данфосс ТОВ" 04080, Київ 80, п/с 168, Україна
* For exact values please refer name plate in unit
A: Model
B: Code number
C: Serial Number and bar code
D: EAN number
E: Refrigerant
F: PED Category
G: Application, Ingress Protection
H: Maximum Allowable Pressure (HP
side)
Picture 2 : Stacked mounting
Picture 4 : Normal wiring
56 | AN37261897352601-010301 - 118A2177C
IP54
Voltage 400V~3N~50Hz
LRA 60 A
MCC 14 A
RLA 8.3 A
A2L
Refrigerant
Danfoss A/S, 6430 Nordborg, Denmark
I: Maximum Allowable Pressure (LP
side)
J: Test Pressure
K: Maximum allowable Design
Temperature
L: Pressure Relief Valve set pressure
V
U
T: Mounting brackets for stacked mounting (not supplied)
U: M8 bolts for stacked mounting (supplied)
V: Mounting bolts (not supplied)
W
Picture 1 : Minimum mounting distances
Unit
Housing 1 (Code no. 114X31-- or 114X41--)
Housing 2 (Code no. 114X32-- or 114X42--)
Housing 3 (Code no. 114x33-- or 114x43--)
T
U
Picture 3 : Electronic controller display
A: Up/Menu button
B: Select / Confirm
C: Down button
V
Picture 5 : Temporary wiring
X
Y
X
X Y
[mm] [mm]
250 550
250 650
250 760
Compressor running
Crankcase heater on
Fan running
Temperature value for suction pressure.
Push lower button to switch to temperature
value for condensing pressure
© Danfoss | Climate Solutions | 2022.02
W
[mm]
460
530
580
A
B
C
