ASSEMBLY INSTRUCTIONS
STEP 7
Attach the Seat (7) to the Seat Frame (6) with four
7
M8 x 15mm Screws (13) and four M8 Washers
(18); start all the Screws, and then tighten them. To
avoid damaging the Seat, tighten the Screws only
6
until the Seat does not move or feel loose.
Note: To adjust the angle of the Seat (7), see
ADJUSTING THE SEAT on page 8.
18
18
13
13
18
13
Make sure that all parts of the weight bench are properly tightened.
Extra parts may be included. Place a mat under the weight bench to protect the floor.
