COMPONENTS
Use the drawings below to identify the small parts needed for assembly. The number in
parentheses below each drawing is the key number of the part, from the PART LIST near
the end of this manual.
Note: If a part is not in the hardware kit, check to see whether it has been preassem-
bled.
Extra hardware may be included.
M8 Washer M12 Washer M12 Locknut
(18)–18 (15)–4 (16)–2
M8 x 15mm M8 x 60mm Screw (21)–2 Stop Screw (17)–2
Screw (13)–16
M12 x 100mm Bolt (14)–2
