FR: INSTRUCTIONS D'ASSEMBLAGE
EN: ASSEMBLY INSTRUCTION
FR: IMPORTANT: A LIRE ATTENTIVEMENT ET A CONSERVER POUR VOUS Y
REFRERER ULTERIEUREMENT
EN: IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
IN240100147V02_UK_FR
A91-134

Werbung

loading

Inhaltszusammenfassung für HOMCOM A91-134

  • Seite 1 IN240100147V02_UK_FR A91-134 FR: INSTRUCTIONS D’ASSEMBLAGE EN: ASSEMBLY INSTRUCTION FR: IMPORTANT: A LIRE ATTENTIVEMENT ET A CONSERVER POUR VOUS Y REFRERER ULTERIEUREMENT EN: IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
  • Seite 2 PACKING DETALS:TOTAL 4 BOXES BOX-1/4 PARTS PARTS PARTS HARDWARE...
  • Seite 3 BOX-2/4 PARTS PARTS PARTS...
  • Seite 4 BOX-3/4 PARTS BOX-4/4 PARTS...
  • Seite 5 TABLE OF CONTENTS SAFETY INFORMATION ........................1 PRODUCT COMPONENT DETAILS ...................... 3 PARTS LIST ............................4 PARTS LIST 1 ............................5 PARTS LIST 2 ............................6 INSTALLATION ............................7 CLEANING AND MAINTENANCE ......................18 DISPOSAL ............................18...
  • Seite 6 SAFETY INFORMATION IMPORTANT – Please read fully before assembly or use. This exercise equipment is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble, operate, or use this equipment, note the following safety precautions.
  • Seite 7 Children or persons with limited physical or mental abilities, or those not familiar with this device, should not be allowed to use this weight bench! Please keep in mind that this manual and the safety can only draw your attention to eventual hazard.
  • Seite 8 PRODUCT COMPONENT DETAILS ~ 3 ~...
  • Seite 9 PARTS LIST Parts Description Parts Description Main base tube 1 pc Rubber Cushion 2 pcs Back base tube 1 pc Weight 9 pcs Front base tube 1 pc Pulley shaft 1 pc Upper Support 1 pc Locking pin 10*150 1 pc Vertical Support 1 pc Pulley Seat...
  • Seite 10 PARTS LIST 1 ~ 5 ~...
  • Seite 11 PARTS LIST 2 ~ 6 ~...
  • Seite 12 INSTALLATION Step 1 1. Attach main base tube(l) to back base tube(2),chrome bar(22)using Hex bolts M10x25(64- 2sets), washers and Hex bolts M8x20 (67- 2sets),wash- ers. 2. Attach main base tube(l) to front base tube(3)using Hex bolts M10x45(61-2sets), washers, nuts, and Hex bolts M8x20(67-2sets), wash- ers.
  • Seite 13 Step 2 1.Attach weights(24, 29) to chrome bars(22) as shown. ~ 8 ~...
  • Seite 14 Step 3 1. Attach Vertical support(5)to Main base tube(I) using reinforced plate (48) and Hex bolts MI0 x50 (60-2sets) washers and nuts. 2. Attach Upper support(4)to Vertical support(5) using reinforced plate (48) and Hex bolts MI0 x50(60-2sets) and insert chrome bars(22) into holes of upper support(4) using Hex bolts M10 x25(64-2sts).
  • Seite 15 Step 4 1. Attach the chest press (10) to upper support 94) using Hex bolts M10 x 45 (61 – 2 sets), washers and nuts 2. Attach the pulley shaft (30), pro support (51) to vertical support (5) using Hex bolts M10 x 50 (51-2sets), washers and nuts ~ 1 0 ~...
  • Seite 16 Step 5 1. Attach the right arm(12) to chest press(10) using steel bushing (42) and Hex bolts M12x85 (56), washer and nut. 2. Insert the handle bar(16) into right arm(12) using Hex bolts M10x25(64),washer. ~ 1 1 ~...
  • Seite 17 Step 6 1. Attach the H- shaped support (13) to the main base tube (1) using the steel busing (42) and Hex bolts M12 x 190 (55), washer and nut 2. Insert the rowing support (9) into the holes of the vertical support (5) using Hex bolts M10 x 25 (64), washer ~ 1 2 ~...
  • Seite 18 Step 7: 1. Attach leg extension(7) to seat support(6) using Hex bolts M10 x75 (58-Isets) washers and nuts. 2. Insert the rowing arm (19) into the H-shaped support (7) using the big washer (41) and Hex bolts M10 x25 (64-2 sets) washers. ~ 13 ~...
  • Seite 19 Step 8: 1. Attach back cushion(50) to vertical support(5) using Hex bolts M8x45(65-2sets) washers . 2. Attach seat pad (46) to seat support (6) using Hex bolts M8x45 (65-2sets) washers ~ 1 4 ~...
  • Seite 20 ~ 15 ~...
  • Seite 21 ~ 16 ~...
  • Seite 22 ~ 17 ~...
  • Seite 23 CLEANING AND MAINTENANCE 1. Regularly examine the equipment to detect any damage to wear which may have occurred. The safety level of the equipment can be maintained only if it is examined regularly for damage and wear and tear on ropes, pulleys, and connection points. 2.
