7.1.2 Setting the cutting depth (Fig. 1)
Undo the locking screw (15) and set the saw
bench (16) to the required cutting depth. The
saw blade (5) should project out of the material
by a few millimeters.
Retighten the locknut (15).
7.1.3 Longitudinal cuts (Figure 4)
Undo the knurled screw (25) and set the cross
and parallel stop (18) to 90°. Tighten the knurled
screw (25) again.
Fit the parallel stop (18) from the right into the
front groove in the saw bench (16).
Undo the two knurled screws (26). Carefully
push the stop rail (27) to over the middle of the
saw blade (5) and secure it.
Set the parallel stop (18) to the required
dimension using the scale (c) on the saw bench
(16) and secure it with the locking screw (28).
Switch on the saw by pressing the green button
(a).
Slide the workpiece slowly and precisely along
the parallel stop (18) to the saw blade (5).
The top saw blade guard (17) will open
automatically and the workpiece moves forward.
Important: For workpiece widths below 120 mm
a push stick (29) must be used in the area near
the saw blade (5) (see Fig. 5) (supplied). For
workpiece widths below 30 mm a push block (d)
must be used to move the workpiece (Fig. 6).
The push block is not supplied. (Available
from your specialist dealer)
Always push the workpiece through to the end of
the splitter (30) (Fig. 7).
After completing the cut the safety hood (17) will
close again automatically to cover the saw blade
(5).
Switch off the saw again.
Important: Secure long workpieces against
falling off at the end of the cut (e.g. with a roller
stand etc.) (e.g. roller table etc.)
7.1.4. Making cross cuts (Fig. 8/9)
Fit the cross parallel stop (18) from the front into
the side groove in the saw bench (16).
Tighten the locking screw (28) until the cross and
parallel stop (18) can be moved in the groove in
the saw bench (16) with a little play.
Undo the knurled screw (25), set the cross stop
(18) to the required angle and secure it.
Undo the two knurled screws (26) and slide the
stop rail (27) to the left until it do not touch the
saw blade guard (17) when it is moved forwards.
Retighten the knurled screws (26).
Switch on the saw.
Press the workpiece firmly against the stop rail
18
24.09.2010 9:05 Uhr Seite 18
(27) and slide it slowly into the saw blade (5)
together with the cross and parallel stop (18) to
complete the cut.
After completing the cut, switch off the saw
again.
7.2. Using as a crosscut saw
Set the saw to crosscut mode (see 6.2.1)
7.2.1 Settings (Abb. 2/3)
When the tightening screw (22) is loosened, you
can tilt the machine head to the left by up to 45°.
The turntable (8) can be adjusted from -45° to
+45° by undoing the locking screws.(10)
Start the saw by pressing the On/Off switch (3).
The switch must remain pressed during the
sawing work.
7.2.2 Crosscut 90° and turntable 0° (Fig. 1)
Press the On/Off switch (3) to turn on the saw.
Important. Place the material for sawing firmly on
the machine surface, to prevent it from moving
during the sawing process.
When you have switched on the saw, wait until
the saw blade (5) has reached maximum speed.
Press the release lever (1) and, using the handle
(2), apply steady and light downward pressure to
move the machine head through the workpiece.
After the cutting process is finished, bring the
machine head back to its upper (home) position
and release the ON/OFF button (3). Important.
The integral resetting springs will automatically
lift the machine head. Do not simply let go of the
handle (2) after cutting, but allow the machine
head to rise slowly, applying slight
counterpressure as it does so.
7.2.3 Crosscut 90° and turntable 0°- 45° (Fig. 10)
The crosscut and miter saw with table can be used to
make right and left angular cuts of 0°- 45° in relation
to the stop rail.
Move the machine head to its upper position.
Release the turntable (8) by slackening the
locking screw (10).
Using the handle (2), set the turntable (8) to the
desired angle, i.e. the marking (a) on the
turntable must coincide with the desired angular
setting (11) on the stationary base plate (9).
Retighten the locking screw (10) to secure the
turntable (8) in place.
Cut as described under section 7.2.2.
7.2.4 Miter cut 0°- 45° and turntable 0° (Fig. 11/12)
The crosscut and miter saw with table can be used to
make miter cuts of 0° - 45° in relation to the work
face.
