EN
STEP 5.
Fix the handlebar (4) to the saddle and seatback column (3)
with bolts (17), flat washers (18), and nuts (11).
Connect the heart rate cables (20) to the heart rate
connecting cables (32).
STEP 6.
Screw the left and right pedal (7 L/R) to the crank (5). Screw
the right pedal bolt (7 R) on clockwise. Screw the left pedal
bolt (7L) counterclockwise.
NOTE! The right pedal is marked 'R', and the left pedal is
marked 'L'.
STEP 7.
Connect the heart rate measurement cable (33) and the
computer cable (34) to cables from the the computer (28).
Fix the computer (28) to the computer bracket on the front
main frame (1) with cross-head bolts (36), and flat washers
(35).
Congratulations!
You have assembled magnetic bike!
Read the manual carefully before using the bicycle.
ADJUSTMENTS
Resistance adjustment
In order to increase the resistance, turn the resistance knob clockwise. In order to decrease the resistance,
turn the resistance knob counterclockwise.
Saddle position
The saddle position (distance to the pedals) is adjusted with the length of the main frame.
Loosen the knob on the main frame. Set the saddle to the desired position and tighten the knob.
Make sure the saddle is secured.
Adjusting pedal straps
Fix the side of the rubber strap with three holes to the internal part of the pedal. Fix the other end to one of
the adjustment opening so that the feet is fixed during training and easy to take out. Repeat for the other
pedal.
22
