Installing handle and reversing the door
1. Install handle to the door frame of the appliance
The handle is delivered in a separated package with screws together inside the carton.
① Reveal two small holes on the door frame from inner side by pulling out a bit the
door seal ② Aim the handle to the holes and insert the screws from inside ③ Screw
them up with screwdriver ④
2. Reversing the door
Our wine coolers are delivered with the door opening from left to
right. To reverse the opening direction:
Refer to picture 1:
1) Close the door.
2) Remove the short cabinet foot① at the bottom right corner,
Unscrew the screws②, Take off the right lower door hinge③,
Move the door down a short distance, then remove the door and
place it aside.
3) Unscrew the screws④, Take off the right upper door hinge⑤,
Take off the hinge hole cover⑥ at the upper left corner, Remove
the cabinet foot⑦ at the lower left corner.
Put back door seal to cover the screws.
Picture 1
EN-5
