Mastbefestigungssatz
Rüstsatz für die Montage des Feldgehäuses
an horizontalen und vertikalen Rohren
(max. ∅ 60 mm);
Material Edelstahl VA; Best.-Nr. 50086842
90
70
∅ 6
70
90
Endress+Hauser
Universalsäule CYY 102
Vierkantrohr zur Montage von Messumfor-
mern; Material 1.4301; Best.-Nr. CYY102-A
M6
120
60 x 60
MONT5.CDR
Bild 3.6
Installation
OM253D03.CHP
links:
Befestigungssatz
für Mastmontage an
zylindrischen Rohren
rechts:
Vierkantiger
Befestigungsmast
CYY 102
