The assembly and commissioning of the SYR HygBox Connect may only be carried out be authorized, qualified and
instructed personnel with the corresponding special knowledge.
The general safety instructions for drinking water installations have to be met, amongst others
•
Drinking water supply systems (TRWI) - DIN 1988, DIN EN 806, DIN EN 1717, VDI 6023
•
Instructions and regulations of the local water supply
Attention!
Potential material damage in case of improper drinking water installation!
•
Mount the HygBox Connect in accordance with the instructions for use.
Check connections for leaks.
•
Avoid water hammers, e.g. from solenoid valves downstream in the system.
Attention!
Dirt in the drinking water supply line can lead to malfunctions in the device.
•
We recommend the installation of a filter (e.g. DRUFI+ DFR) at the point of entry of
domestic water installations to protect the installation downstream!
Attention!
Potential material damage in case of improper electrical installation!
•
Use only the supplied mains adapter to connect the device to the mains.

6.1. Mounting the HygBox

•
Drill two holes (Ø 6mm) and mount the wall bracket
using the enclosed plugs and screw.
Alternatively, you can use the „Adhe-
sive set for wall holder" (2622.00.909)
accessory.
A precise description is included with
the adhesive set.

6. Assembly
