11.2 Example 2: Reporting a problem to the shift manager
and signalling help
Scenario
– The operator and shift manager have an Andon WirelessBOX with 2 buttons.
Process
The operator needs help and presses button 2 of their Andon WirelessBOX.
Button 2 of the operator's Andon WirelessBOX lights up red.
The operator's signal tower lights up red.
Button 2 of the shift manager's Andon WirelessBOX lights up red.
The shift manager presses button 2 of their Andon WirelessBOX to confirm that they are coming to
help.
Button 1 of the shift manager's Andon WirelessBOX blinks green.
The operator's signal tower blinks green.
Button 1 of the operator's Andon WirelessBOX blinks green.
After the problem has been resolved, the operator presses button 1 of their Andon WirelessBOX.
Button 1 of the operator's Andon WirelessBOX is off.
The operator's signal tower is off.
Button 1 of the shift manager's Andon WirelessBOX is off.
Configuration of the Andon WirelessBOXes
Operator's Andon WirelessBOX
