Specification of Modules

Skeleton

The Skeleton, "bone" of the ClicBot, is used for connecting limbs of
the robot. There are two connectors, locating at the top and bottom
of the Skeleton. Two strip status indicators are located on the front,
which show the connection and update status.
Size
Weight
Connector
position
*Status of Skeleton's indicator
37.8*37*120 mm
The color of Skeleton's indicator can be changed via graphical
50 g
programming.
Upper and
bottom rear side
6
English
Connection Status
Light on Connected correctly
Flashing Waiting for module
connection
Flashing quickly Wrong
connection
Update Status
Light on Updated successfully
Flashing Module needs updating
ID
light strip
