Specification of Modules
Smart Foot
The Smart Foot is a functional sensor module that serves as the 'feet'
of the ClicBot. The Smart Foot includes a highly sensitive pressure
sensor and a micro-processor to control and measure terminal
pressure.
Size
Weight
Pressure detection
range
Connector position
Do not apply too much pressure, otherwise the pressure
detection function of Smart Foot may be damaged.
Smart Foot
Above the Smart Foot, there is an orange indicator. After connecting
onto ClicBot, the luminance of the indicator will change along with the
pressure. The indicator can also indicate the connection status and
update status.
41.8*41.8*71.2 mm
50g
2N
Upper side
Connection Status
Light on Connected correctly
Flashing Waiting for module connection
Flashing quickly Wrong connection
9
English
Update Status
Light on Updated
successfully
Flashing Module
needs updating
