Specification of Modules

Brain

The Brain is the master control and power supply unit of the ClicBot. It
uses an ARM-A7 processor and includes a rechargeable polymer
lithium battery with a capacity of 1550mAh. The eye of the ClicBot is
a 2.1-inch rotational, circular touch screen. Visual sensors, gesture
sensors and camera lights are located at the upper-left corner. There
are three touch sensors located on the upper, left, and right side of
the Brain respectively; two connectors are located on the upper and
bottom rear side. The Brain also contains such functional modules as
accelerometer, gyroscope, microphone, loudspeaker, and Wi-Fi
module.
Size 66.7*66.5*124.8 mm Touch sensors
Weight
275g Microphone
Touch screen size 2.1" Loudspeaker
Screen rotate angle -24° - +24° WiFi
Battery
2-megapixel
Charge port
Support face
detection &
Connector
Camera
recognition, motion
detection
Recognition
distance 5m
8 gestures can be
Gesture recognition
recognized at a
sensors
distance of 20cm
Brain
Gesture sensors
Camera light
Camera
Touch sensors
Upper, left and right side
Support volume detection
Single track
2.4 G/5G
1550mAh
USB-C
Upper and bottom
rear side
4
English
Power supply light
Touch screen
Power button
Type-C charge port
Microphone
