Specification of Modules

Suction Cup

The Suction Cup is a functional actuator module. The Suction Cup
includes a negative pressure pump and a solenoid valve. By utilizing a
micro-processor, it can control the air current and on/off the vacuum,
allowing the ClicBot to perform climbing functions. It also uses the air
pressure sensor to proactively check the stability of the ClicBot's
movement.
Size 83*83*91 mm
Weight 200 g
Maximum weight in vertical direction 20
Suction weight
kg
Maximum weight in horizontal direction
5 kg
Connector position Bottom
Suction Cup
Suction Cup has a green indicator. The indicator presents breathing
effect when Suction Cup is functioning and stays on if the suction is
successful. The indicator can also indicate the connection and update
status.
Connection Status
Light on Connected correctly
Flashing Waiting for module connection
Flashing quickly Wrong connection
10
English
Update Status
Light on Updated
successfully
Flashing Module
needs updating
