Specification of Modules

Distance Sensor

The Distance Sensor is a functional sensor module, which uses a high-
precision infrared probe and built-in micro-processor to control and
measure the distance from an obstacle.
Size 40*40*82.4 mm
Weight 60 g
Detection distance
2-100 cm
range
Degree of freedom Control range of universal joint at the Bottom: 0° ~ 180°
control Body left-right rotation control range: -90°~ 90°
Connector position Bottom
Distance Sensor
It has a red indicator. After connecting Distance Sensor, the
luminance of indicator will become brighter when the distance is
shortening. The indicator can also indicate the connection status and
update status.
Connection Status
Light on Connected correctly
Flashing Waiting for module connection
Flashing quickly Wrong connection
11
English
Update Status
Light on Updated
successfully
Flashing Module
needs updating
