Iluminarc LOGIC MR16 Downlight S Schnellanleitung Seite 6

EN
Menu Map
Access the LΩGIC MR16 Downlight S menu through the LΩGIC Drive 2X Linked Fixtures menu.
Refer to the LΩGIC MR16 Downlight S and LΩGIC Drive 2X product pages on
maps.
Main Level
Dmx Address
Personality
Net Switch
Network
Universe
Version
IP Address
Fixture Hours
Local Info Label
Device UID
MAC Address
Temperature
Factory Reset
5
QUICK REFERENCE GUIDE
Programming Levels
001–512
RED
GREEN
BLUE
WHITE
TW
RGB
RGBW
RGBW+D
FULL
2.X.X.X
10.X.X.X
000–255 / 001–256
(Art-Net™)
V _._ _
_ _ _._ _ _._ _ _._ _ _
_ hours
_ _ _ _ _ _ _ _ _ _
_ _ _ _ _ _-_ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _ _ _ _ _ _ _
_ _._ °C
No
Yes
www.iluminarc.com
Description
Selects DMX address
1-channel: dimmer (red only)
1-channel: dimmer (green only)
1-channel: dimmer (blue only)
1-channel: dimmer (white only)
2-channel, Tunable White: dimmer, color
temperature
3-channel: RGB control
4-channel: RGBW control
5-channel: dimmer, RGBW control
10-channel: dimmer, RGBW, color macros, strobe,
auto programs and speed, dimmer speed
Selects the first value of the IP address
Selects universe
(sACN)
Shows current firmware version
Shows the IP address
Shows length of time product has been on
Shows product label
Shows device UID
Shows the MAC address
Shows the current temperature in °C
Resets to factory default settings
LΩGIC MR16 Downlight S QRG Rev. 5
for the latest menu
