Technical Specifications - Iluminarc LOGIC MR16 Downlight S Schnellanleitung

EN
RED (1 Channel)
Channel Function
1 Dimmer

Technical Specifications

Dimensions and Weight
Product
LΩGIC MR16 Downlight S
LΩGIC MR16 TRIM
LΩGIC MR16 HF
Note: Dimensions in inches are rounded.
Power
Power Source
Power Over Ethernet
Single Fixture Power
8.3 W via POE
Power I/O
Power input connector
Power output connector
Cable type (required)
Light Source
Type
LED
Photometrics
Filter
Open optics
Medium (pre-installed)
Medium w/HF
Wide (included)
Wide w/HF
Cabling
Total Max Cable Length
(Fixture to Fixture)
328 ft (100 m)
Thermal
Ambient Temperature Range
-4 °F to 113 °F (-20 °C to 45 °C)
Ordering
Product Name
LΩGIC MR16 Downlight S
LΩGIC MR16 TRIM
LΩGIC MR16 HF
9
QUICK REFERENCE GUIDE
Value
000  255 Red only, 0–100%
Length
1.96 in (50 mm)
2.83 in (71.83 mm)
1.68 in (42.7 mm)
Total Linking Power per Port/POEI
Color Quantity
RGBW 1
Beam Angle
30.9°
40.4°
33.6°
41.8°
34.2°
Cable Diameter Range
Less than 50 ft (15 m)
23-24 AWG (shielded or unshielded)
Item Name
LOGICMR16DNS
LOGICMR16TRIM
LOGICMR16HF
Percent/Setting
Width
1.96 in (50 mm)
2.83 in (71.83 mm)
1.68 in (42.7 mm)
Input Voltage
48-52 VDC
66.4 W via POE
U.S./Worldwide
Ethernet RJ45
Ethernet RJ45
CAT6
Power
10 W
Field Angle
59.7°
81.7°
63.9°
105.5°
64.3°
Cooling
Convection
Item Code
1541735
1541818
1651832
Height
4.59 in (116.80 mm)
1.3 in (33 mm)
0.61 in (15.5 mm)
Voltage Selection
Fixed
Power Linking
8 products per port/POE injector
UK/Europe
Ethernet RJ45
Ethernet RJ45
CAT6
Current
4.375 A
Cutoff Angle Illuminance @ 5 m
82.8°
148.9°
84.7°
154.3°
90°
Cable Diameter Range
50-328 ft (15-100 m)
23 AWG (shielded)
UPC Number
781462220839
781462221669
781462221805
LΩGIC MR16 Downlight S QRG Rev. 5
Weight
0.39 lb (0.18 kg)
2.8 oz (79.83 g)
0.6 oz (17 g)
Lifespan
50,000 hours
29 lux
11 lux
9 lux
8 lux
8 lux
