Reversing The Door - Cavecool CC201DB Bedienungsanleitung

Installing handle and reversing the door
1. Install handle to the door frame of the appliance
The handle is delivered in a separated package with screws
together inside the carton.
① Reveal two small holes on the door frame from inner side by
pulling out a bit the door seal ② Aim the handle to the holes and
insert the screws from inside ③ Screw them up with screw-
driver ④ Put back door seal to cover the screws.

2. Reversing the door

Our wine coolers are delivered with the door opening from left to right. To reverse the
opening direction:
Refer to picture 1:
1) Close the door.
2) Remove the short cabinet foot① at the bottom right corner, Unscrew the screws②,
Take off the right lower door hinge③, Move the door down a short distance, then
remove the door and place it aside.
3) Unscrew the screws④, Take off the right upper door hinge⑤, Take off the hinge hole
cover⑥ at the upper left corner, Remove the cabinet foot⑦ at the lower left corner.
Picture 1
EN-5
