Thunder- • Intel® JHL8540 Thunderbolt
TM
bolt • Supports Thunderbolt
5K (5120 x 2880) @ 60Hz for one display over a single cable
connection
• Supports Thunderbolt
4K x 2K (4096x2160) @ 60Hz for dual displays over a single
cable connection
* DisplayPort or USB-C monitor is not supported on the
Thunderbolt
* A discrete graphics card is required for Thunderbolt display
Graphics • Aspeed® AST2500 BMC Controller
• Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
Audio • 7.1 CH HD Audio (Realtek ALC4050H+ALC1220)
• Premium Blu-ray Audio support
• Supports Surge Protection
• NE5532 Premium Headset Amplifier for Front Panel Audio
Connector (Supports up to 600 Ohm headsets)
• Pure Power-In
• Direct Drive Technology
• PCB Isolate Shielding
• Impedance Sensing on Rear Out port
• Individual PCB Layers for R/L Audio Channel
• Gold Audio Jacks
• 15μ Gold Audio Connector
• Nahimic Audio
LAN 2 x 10 Gigabit LAN 100/1000/2500/5000/10000 Mb/s (Intel®
X710-AT2)
• Supports Lightning/ESD Protection
• Supports Energy Efficient Ethernet 802.3az
• Supports PXE
1 x Dedicated IPMI (ASPEED AST2500)
• Supports iKVM and vMedia
TM
4 Controller
TM
4 interface with max. resolution of
TM
4 interface with max. resolution of
TM
4 Type-C Ports
