Installation
Step 1
Prepare two Mini DisplayPort to DisplayPort Adapter Cables and one/two
TM
Thunderbolt cables. All these cables are not included in the package.
Step 2
Connect one end of the Mini DisplayPort to DisplayPort Adapter Cable to the Mini
DisplayPort Input Port (A) on ASRock Thunderbolt
Then connect the other end of the cable to the DisplayPort Output Port (B) on the
graphics card.
A
TM
4 Module on I/O panel.
B
WRX80 Creator
