Pkm GH6-90B5D Bedienungsanleitung Seite 146

4. Push the rotary knob (A) back onto the rotary knob shaft properly. The mark of
the rotary knob (A 1) must face the minimum level (D / s. fig. below).
A
A 1
D
5. Check that the minimal-flame of the burner-jet is adjusted correctly and properly:
the minimal-flame is adjusted correctly and properly when the flame does not go
off when rapidly turning the rotary knob from maximum level (E) to minimum
level (D): s. fig. below.
Fig. similar: modifications are possible.
Fig. similar: modifications are possible.
M
ARK OF THE ROTARY KNOB
M (minimal-flame / minimum gas supply)
INIMUM LEVEL
~
R
OTARY KNOB
~
146
