2.9.2 LPG: adjustment of the burner-jets to minimal-flame
I
NSTRUCTIONS FOR THE QUALIFIED PROFESSIONAL
❖ The minimal-flame must be adjusted properly for all burner-jets even when the
appliance is supplied with LPG.
1. Ignite a gas burner (s. chapter 4.2.5 I
minimum level «
(A 1) must face the minimum level (D / s. fig. below).
To ignite a gas burner, turn the respective rotary knob to the minimum level (D)
in anticlockwise direction only, otherwise you may damage the rotary knob.
2. Then pull off the rotary knob (A).
A
A 1
B
C
D
E
3. Then adjust the minimal-flame of the burner-jet properly. To adjust the minimal-
flame of a burner-jet with LPG supply, the relevant screw of the gas burner must
be completely tightened in clockwise direction (one whole turn / 360°) using
a flat-head screwdriver (s. fig. below).
» (D) using the rotary knob (A). The mark on the rotary knob
Fig. similar: modifications are possible.
M
ARK OF THE ROTARY KNOB
P
OSITION OF THE GAS BURNER
G
AS BURNER
M
(minimal-flame / minimum gas supply)
INIMUM LEVEL
M
AXIMUM LEVEL
~
GNITION OF A GAS BURNER
R
OTARY KNOB
(cooking zone)
« O
» (no gas supply)
FF
(maximum gas supply)
~
145
(
)
GAS FITTER
