2.8 PC Health Status

►
ABIT FanEQ Control
FAN Fail Alarm Selectable
Shutdown When FAN Fail
CPU Shutdown Temperature
CPU Warning Temperature
CPU Temperature
SYS Temperature
PWM Temperature
CPU FAN Speed
SYS FAN Speed
AUX1 FAN Speed
AUX2 FAN Speed
CPU Core Voltage
DDR2 Voltage
DDR2 VTT Voltage
MCH Voltage
ATX +12V
ATX +5V
ATX +3.3V
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values
ABIT FanEQ Control
This item determines the temperature threshold to raise the fan attached at CPU and SYS fan
headers up to their full speed.
Click <Enter> key to enter its submenu:
CPU FanEQ ontrol
- FanEQ Target Tempe.
- FanEQ Temp. Tolerance
- FanEQ Start Control
- FanEQ Stop Control
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values
CPU FanEQ Control
This item allows you to control the CPUFAN speed. When set to [Enabled], the following items
become selectable.
- FanEQ Target Temp
This item sets the temperature mark for the "CPU FanEQ" function to take effect.
- FanEQ Temp. Tolerance
This item sets the temperature tolerance range for the item "FanEQ Target Temp.".
2-18
Phoenix – AwardBIOS CMOS Setup Utility
PC Health Status
Press Enter
Disabled
Disabled
90 ° C/ 194 ° F
85 ° C/ 185 ° F
35 ° C/ 95 ° F
32 ° C/ 89 ° F
35 ° C/ 95 ° F
3245 RPM
4218 RPM
F6: Fail-Safe Defaults
Phoenix – AwardBIOS CMOS Setup Utility
ABIT FanEQ Control
Enabled
50 ° C/122 ° F
5 ° C/ 41 ° F
80%
50%
F6: Fail-Safe Defaults
0 RPM
0 RPM
1.30V
1.80V
0.88V
1.25V
12.00V
5.00V
3.30V
F7: Optimized Defaults
F7: Optimized Defaults
Item Help
Item Help
IB9
