2.3 Advanced BIOS Features

CPU L3 Cache
Hyper-Threading Technology
Quick Power on Self Test
► CPU Feature
► Hard Disk Boot Priority
First Boot Device
Second Boot Device
Third Boot Device
Boot Other Device
Boot Up Floppy Seek
Boot Up NumLock Status
Security Option
MPS Version Ctrl For OS
Report No FDD for OS
Delay IDE Initial (Secs)
Full Screen Logo Show
Disable Unused PCI Clock
:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values
CPU L3 Cache
This item is used to enable the L3 cache (default setting), and appears only for certain CPU
(Intel Pentium 4 processor with HT Technology Extreme Edition) that possesses L3 cache.
Hyper-Threading Technology
This item is used to enable the functionality of the processor with Hyper-Threading Technology
and will appear only when using such processor.
The Hyper-Threading Technology helps your PC work more efficiently by maximizing processor
resources and enabling a single processor to run two separate threads of software
simultaneously, bringing forth greater performance and system responsiveness when running
multiple applications at once.
Quick Power On Self Test
When set to [Enabled], this item speeds up the Power On Self Test (POST) after powering on
the system. The BIOS shorten or skip some check during the POST.
IB9
Phoenix – AwardBIOS CMOS Setup Utility
Advanced BIOS Features
Enabled
Enabled
Enabled
Press Enter
Press Enter
Floppy
Hard Disk
SATA CDROM
Enabled
Disabled
On
Setup
1.4
No
0
Enabled
Yes
F6: Fail-Safe Defaults
Item Help
F7: Optimized Defaults
2-7
