Outer lange
5.
Inner lange
6.
* Slight diferences may appear between the product and drawing
MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY/SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
1. Disc guard
2. Special key
3. Additional handle
INSTALLATION OF ADDITIONAL HANDLE
Additional handle (3) can be installed in one of the holes on the grinder head. Use of the grinder with
additional handle is recommended. When holding the grinder with both hands (using additional handle),
risk of touching rotating disc or brush with your hand is reduced.
DISC GUARD INSTALLATION
When using wire brush or dished, elastic or cutting wheel, install guard (4) onto the grinder so its shield
faces the operator.
4) so the protrusion on its clip matches cut-out on the grinder gear casing.
Install disc guard (
●
Install the disc guard in desired position.
●
Screw the ixing screws irmly.
●
Deinstallation and adjusting the disc guard are similar to installation, only the sequence of actions is
reversed.
REPLACEMENT OF WORKING TOOLS
Disc lock button (1) is used to lock the grinder spindle.
Press the disc lock button (
●
Insert special key (included) to two holes located on the outer lange (
●
Turn the key and loosen outer lange (
●
Remove the lange and disc.
●
Installation of disc is similar to deinstallation, only the sequence of actions is reversed. During installation,
the disc should be pressed against surface of the inner lange (6). In case of abrasive or cutting wheels less
than 3 mm thick, outer lange (5) nut must be screwed with lat surface to the side of the wheel (ig. B).
Disc lock button (1) can be used only for installation and removal of the disc. It cannot be used as a
brake-button while the disc is rotating, otherwise the grinder may be damaged or the user may be
injured.
- 1 pce
- 1 pce
- 1 pce

PREPARATION FOR OPERATION

1).
5).
11
5) (ig. A).
