1.

TECHNICAL DATA

1.1

TECHNICAL CHARACTERISTICS

STRUCTURE
Stainless steel frame AISI 304, stainless steel panels and base mounted on height-adjustable feet.
COOKTOP
TOP in stainless steel AISI 304 seal tight.
GRILLS in porcelained cast iron, high-temperature resistant.
BURNERS in chromate cast iron, flame-spreader made of brass with stabilised fire, ignition by pilot flame, fixed nozzles for
various types of gas.
GAS COCKS in pressed brass, supplied with safety valve and thermocouple for automatic interruption of gas flow in case of
accidental pilot extinguishment.
CONTROL KNOBS in heat-insulated material.

GAS SOLID TOP

COOKING PLATE made of non-deformable special steel with extractable central "fast-cooking-zone" disc.
BURNER made of AISI 304 stainless steel with stabilised flame; ignition by "Targhet" pilot flame, with fixed nozzles for
various types of gas.
PIEZOELECTRIC IGNITION of the pilot burner.
GAS COCK of pressed brass, supplied with safety valve and thermocouple for automatic gas interruption in case of accidental
pilot extinguishment. Adjustment between minimum and maximum capacity.
COMBUSTION CHAMBER made of AISI 304 stainless steel insulated by way of ceramic fibres (Aluminium Oxide and Silicon
Monoxide).
WINDSCREEN/DRAFT HOOD may be supplied as an optional; (Type B ).
